onsemi 1 4-Input OR NOR Logic Gate, Surface Mount, 8-Pin SOIC MC100EL01DG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 5mm |
| Model | MC100EL01DG |
| Mount Type | Surface |
| Output type | ECL |
| Series | 100EL |
| Input Type | ECL |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Number of Elements | 1 |
| Maximum Supply Voltage | 5.7V |
| Logic Family | ECL |
| Logic Function | OR NOR |
| Minimum Supply Voltage | 4.2V |
| Maximum Propagation Delay Time @ CL | 350ps |
| Number of Inputs per Gate | 4 |
Key Features
- Features a 4-input OR/NOR logic gate functionality.
- Operates over a temperature range of -40°C to 85°C.
- Designed with ECL logic family and input type.
- Maximum propagation delay time at CL is 350 picoseconds for fast switching.
- Operates at supply voltages ranging from 4.2 V to 5.7 V depending on mode.
- Compact SOIC package with 8 pins for surface mount applications.
- Includes internal input pulldown resistors for stable operation.
- Protected against electrostatic discharge with > 1 KV HBM and > 100 V MM ratings.
Product Description
onsemi MC100EL01DG is a 1 4-input OR/NOR logic gate designed for surface mount applications in an 8-pin SOIC package. It belongs to the ECL logic family and offers high-speed switching with a maximum propagation delay of 350 picoseconds. This device operates effectively over a wide temperature range from -40°C to 85°C and supports supply voltages from 4.2 V to 5.7 V depending on the operating mode, including PECL and NECL modes.
The MC100EL01DG is functionally equivalent to the E101 device but provides superior performance and temperature compensation from the 100EL series. The device features internal input pulldown resistors to ensure stable logic levels and high immunity to noise. It also includes electrostatic discharge protection with ratings greater than 1 KV human body model and 100 V machine model, enhancing reliability in industrial and commercial electronic applications.
This logic gate IC is ideal for use in high-speed data processing, telecommunications, and other electronic systems requiring ultra-fast logic gate operation. Its compact SOIC package facilitates easy integration into printed circuit boards for surface mount technology, making it suitable for high-density circuitry design.
4-input OR/NOR gate logic functionality. Maximum propagation delay of 350 ps for fast signal processing. Operates between -40°C to 85°C for wide environmental tolerance. Integrated input pulldown resistors enhance noise immunity.
ESD protection exceeding 1 KV HBM and 100 V MM standards. Compact 8-pin SOIC surface mount package. ECL logic family ensures high-speed electronic performance. Supports both PECL and NECL operating voltage ranges.
Used widely in industrial and commercial electronics manufacturing, MC100EL01DG serves applications involving fast switching logic functions such as digital signal processing, industrial control, telecommunications, and embedded systems requiring reliable and high-speed logic operations. It offers a combination of compact size, performance, and environmental robustness required in advanced semiconductor devices.
Explore more semiconductor and Logic Gate solutions at EnvMart for enhanced industrial electronic assemblies and precision circuit design.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum propagation delay time for the MC100EL01DG is 350 picoseconds at CL, allowing for fast signal processing.
This model operates effectively over a temperature range of -40°C to 85°C, making it suitable for various environmental conditions.
The MC100EL01DG supports supply voltages ranging from 4.2 V to 5.7 V, depending on the operating mode.
It comes in a compact 8-pin SOIC surface mount package, facilitating easy integration into printed circuit boards.
This logic gate belongs to the ECL (Emitter Coupled Logic) family, which is known for high-speed electronic performance.
The MC100EL01DG features 4 inputs per gate, allowing for versatile logic operations.
Yes, it includes internal input pulldown resistors to ensure stable logic levels and enhance noise immunity.
The MC100EL01DG is designed to perform OR and NOR logic functions, making it versatile for various applications.
The dimensions of this model are 1.5 mm in height and 5 mm in length.
This logic gate is widely used in high-speed data processing, telecommunications, and embedded systems requiring reliable and fast logic operations.
The output type of the MC100EL01DG is ECL, which is characteristic of high-speed logic devices.
It is protected against electrostatic discharge with ratings exceeding 1 KV HBM and 100 V MM, enhancing reliability in electronic applications.
