Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 20A, Type C, 240V AC, 48V DC, 10kA Breaking Capacity 278675 FAZ-C20/1N
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 278675 FAZ-C20/1N |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 66mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Rated AC Voltage | 240V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| MCB Module widths | 1P 17.5mm, 2P 35mm and 3P 52.5mm |
Key Features
- This single-pole MCB operates at 240V AC and 48V DC voltage ratings.
- It offers a 10kA breaking capacity for safe interruption of short circuits.
- The device includes a thermal magnetic tripping mechanism for reliable overload and short circuit protection.
- Designed for DIN rail mounting with screw terminal connection for secure installation.
- IP20 finger-safe rating makes it suitable for industrial and commercial electrical panels.
- The module width is a compact 17.5mm per pole, enabling space savings in distribution boards.
- The toggle switch actuator clearly indicates contact position and incorporates a trip-free mechanism.
- It complies with IEC 60947-2 and related international standards ensuring high safety and quality.
Product Description
The Eaton xEffect FAZ series Miniature Circuit Breaker model 278675 FAZ-C20/1N is engineered for robust protection of electrical circuits in industrial, commercial, and residential applications.
This 1-pole MCB provides 20 ampere current rating with type C thermal magnetic tripping characteristics, suitable for moderate inrush current loads. Operating with rated voltages of 240V AC and 48V DC, it ensures protection across varying electrical environments.
Featuring a breaking capacity of 10kA, the MCB safely interrupts potentially damaging short-circuits to prevent equipment and wiring damage. The trip-free toggle switch and finger-proof IP20 design enhance user safety during installation and maintenance.
The compact 17.5mm width per module conveniently fits into standard DIN rail setups, optimizing panel space utilization. Screw terminals provide reliable wire connections, facilitating quick and sturdy mounting.
Compliant with IEC 60947-2 and related standards, the FAZ range guarantees high performance and adherence to international electrical safety norms. This model is ideal for distribution boards, control panels, and circuit protection in diverse industrial and commercial environments.
This MCB includes dual thermal and electromagnetic overcurrent protection mechanisms. Its compact size reduces panel space requirements while maintaining high protection levels. Suitable for use in control circuits, lighting, motor protection, and general power distribution.
The breaker cannot be manually overridden to stay in the ON state, enhancing safety. Choose Eaton FAZ series MCBs for reliable, quick-acting circuit protection that meets stringent industry standards and delivers lasting performance.
Explore more high-quality circuit protection devices within Eaton’s xEffect range and related products on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 20A.
It operates at rated voltages of 240V AC and 48V DC.
The breaking capacity is 10kA, allowing it to safely interrupt short circuits.
It features Type C thermal magnetic tripping characteristics, suitable for moderate inrush current loads.
This miniature circuit breaker is designed for DIN rail mounting.
It has an IP20 rating, indicating it is finger-safe.
The width is 66mm and the depth is 80mm, with a compact module width of 17.5mm per pole.
It uses screw terminals for reliable wire connections.
The toggle switch actuator clearly indicates the contact position and incorporates a trip-free mechanism for enhanced safety.
It complies with IEC 60947-2 and related international standards for electrical safety.
This model is suitable for use in control circuits, lighting, motor protection, and general power distribution.
