Weidmüller Panel Power Relay 115V AC Coil 5A Switching Current 4PDT DRM Series 7760056103

Weidmüller 7760056103 Panel Power Relay is a high-quality DRM series power relay featuring a 115V AC coil voltage and 5A switching current, designed specifically for industrial and panel applications.

The relay uses a 4PDT contact configuration with durable silver alloy contacts, ensuring reliable switching and resistance to wear caused by arcing during operation. Thanks to integrated arc suppression technologies such as series connected contacts and built-in blow magnets, this relay offers a significantly longer service life than conventional relays.

Designed for panel mounting, the relay includes plug-in terminals that simplify installation and maintenance. Its compact build, measuring 28 mm in height, 36 mm in width, and 21.5 mm in length, optimizes panel space without compromising performance. The coil resistance of 4340 ohms matches the 115V AC coil voltage requirements, along with a switching AC voltage rating of 250V AC, making it suitable for a wide variety of control and automation tasks.

The operating temperature range from -40°C to 55°C ensures stable performance under diverse environmental conditions. It conforms to cURus standards, denoting compliance with North American safety and quality regulations.

This power relay is ideal for demanding industrial applications involving control of actuators and devices where reliable switching performance and long service life are critical. Its robust build and features minimize maintenance and replacement costs, contributing to efficient system uptime.

The relay belongs to the reliable DRM series, optimized for long service life. It features a panel mount type with plug-in terminals for easy installation. Contact configuration is 4PDT with silver alloy contacts to ensure durability.

Coil resistance is 4340 ohms, and switching AC voltage rating is 250V AC. Operating temperature range spans from -40°C to 55°C for robust performance. Compact dimensions: height 28mm, width 36mm, length 21.5mm to fit control panels.

Equipped with built-in arc suppression features like blow magnets for reduced contact wear. Meets cURus standards for industrial and panel power relay applications. Manufactured in China with stringent quality control for consistent operation.
