Weidmüller Panel Power Relay 24V AC Coil 5A Switching Current 4PDT DRM Series 7760056083

Weidmüller 7760056083 Panel Power Relay is a DRM series power relay designed specifically for demanding industrial applications where reliable switching and long service life are essential. It operates with a 24V AC coil voltage and supports a switching current of 5A, suitable for controlling actuators and loads in industrial environments.

The relay features a 4PDT (four-pole double throw) contact configuration, allowing versatile electrical control setups. With a compact design measuring 21.5mm in length, 36mm in width, and 28mm in height, it is optimized for panel mounting with plug-in terminals to facilitate easy installation and maintenance.

The contacts are made from silver alloy, offering high conductivity and durability. This material choice combined with internal blow magnets and series connected contacts effectively reduces contact arcing, significantly extending the relay's operational lifespan under heavy electrical loads.

Operable in temperatures ranging from -40°C to 55°C, this relay is robust against environmental stresses commonly encountered in industrial settings. Its coil resistance of 160 ohms balances efficient coil current and reliable activation.

The product complies with cURus safety and quality standards, ensuring dependable performance and adherence to regulatory requirements. Manufactured in China, it reflects consistent manufacturing excellence under Weidmüller's DRM series standards.

Panel mounting design with plug-in terminals offers straightforward installation. 4PDT contact configuration provides versatile switching capabilities. Silver alloy contacts minimize wear and ensure reliable conductivity.

Built-in arcing suppression features enhance service life. Wide operating temperature range supports various industrial environments. Compact dimensions allow integration into control panels. Coil resistance of 160Ω supports stable coil operation.

Meets cURus standard certifications for quality assurance. Ideal for automation, electrical control, and signal conditioning applications. Manufactured to deliver consistent industrial-grade performance.

This power relay is suitable for industrial automation systems, electrical panel controls, signal conditioning, manufacturing equipment, and other industrial and commercial applications requiring reliable and durable relay switching. Explore the range of Power Relays at EnvMart to find the perfect component for your electrical and control projects.
