Schneider Electric Power Relay, 120V AC Coil, 3A Switching Current, 4PDT, Plug-In Terminal RXM4GB1F7

Free Delivery in India | Lowest Global Shipping Charges

Schneider Electric Power Relay, 120V AC Coil, 3A Switching Current, 4PDT, Plug-In Terminal RXM4GB1F7

Name: Schneider Electric Power Relay, 120V AC Coil, 3A Switching Current, 4PDT, Plug-In Terminal RXM4GB1F7
Brand: Schneider Electric
SKU: 384949
Price: 22.18 USD
Availability: InStock



Category Power Relay Brand Schneider Electric Condition New

Specifications

Country of Origin	China
Brand	Schneider Electric
Height	27mm
Length	21mm
Model	RXM4GB1F7
Width	47.7mm
Contact Material	Gold Plated
Series	Harmony Relay RXM
Maximum Operating Temperature	55°C
Contact Configuration	4PDT
Minimum Operating Temperature	-40°C
Switching Current	3A
Terminal type	Plug-In
Standards/Approvals	CE, CSA
Coil Resistance	3.6kΩ
Coil Voltage	120V ac
Switching DC Voltage	28V dc
Switching AC Voltage	250V ac
Coil Power	1.2W

Key Features

This miniature power relay operates with a coil voltage of 120V AC.
It has a 4PDT (four-pole double throw) contact configuration for versatile switching.
The relay supports a switching current of up to 3 amperes.
Equipped with plug-in terminals for easy installation and replacement.
Compact size with dimensions of 47.7mm width, 21mm length, and 27mm height.
The coil power consumption is low at 1.2W, ensuring energy efficiency.
Gold plated contacts ensure reliable conductivity and long service life.
Operates reliably in temperatures ranging from -40°C to 55°C.

Product Description

Schneider Electric RXM4GB1F7 power relay is a high-quality miniature relay designed for industrial and electrical automation applications. It features a coil voltage of 120V AC and supports a switching current of 3A, making it ideal for controlling circuits in machines and building equipment.

This relay utilizes a 4PDT contact configuration, allowing multiple contacts to switch simultaneously for complex control schemes. The plug-in terminal type facilitates quick installation and easy replacement in existing systems.

Constructed under the Harmony Relay RXM series, this model offers compact dimensions of 47.7mm width, 21mm length, and 27mm height. Its coil power is very efficient at 1.2W, reducing energy consumption during operation.

The relay contacts are gold plated to ensure excellent conductivity and resilience against wear. It is rated to operate reliably across an industrial temperature range from -40°C to 55°C and complies with CE and CSA quality standards, reinforcing its suitability for stringent industrial, HVAC, manufacturing, and electrical enclosure environments.

This miniature relay operates with a coil voltage of 120V AC. 4PDT contact configuration enables versatile circuit control. Maximum switching current is 3 amperes for reliable load management. Easy to install with plug-in terminal type design.

Compact size suitable for space-saving electrical panel installations. Low coil power consumption of 1.2 watts enhances energy efficiency. Gold plated contacts support durable and stable electrical connections. Operating temperature range from -40 to 55 degrees Celsius suits industrial environments.

Certified to CE and CSA standards for safety and performance. Manufactured in China under Schneider Electric's Harmony RXM series quality assurance.

This power relay is widely used in electrical enclosures, industrial automation systems, HVAC controls, and manufacturing equipment requiring reliable switching. Its plug-in design and compact dimensions simplify integration and maintenance tasks.

Explore the Schneider Electric Power Relay RXM4GB1F7 in the EnvMart catalog for trusted electrical and automation components that meet industrial standards.
