Eaton xPole Miniature Circuit Breaker 2-Pole 32A Type D 48 V DC 10 kA Breaking Capacity 242431 PLSM-D32/2-MW

Eaton 242431 PLSM-D32/2-MW xPole Miniature Circuit Breaker is a high-quality 2-pole MCB designed for commercial and residential DC circuit protection applications. Rated for 32 amps with a Type D tripping characteristic, it operates at 48 V DC systems providing reliable protection against overcurrents and short circuits with a breaking capacity of 10 kA.

This MCB features an instantaneous break time for prompt disconnection, enhancing the safety of electrical installations. It is mounted on a DIN rail using a secure 3-position clip system, enabling quick installation and removal while ensuring stable mounting during operation.

The compact dimensions with an 80mm width and 75mm depth allow flexible fitting in distribution boards and electrical panels. The toggle switch reset actuator supports easy manual reset and operation, while the red-green contact position indicator gives clear visual feedback on circuit status.

The unit complies with IEC/EN 60898-1 standards and carries an IP20 protection rating to prevent ingress of solid foreign objects, suitable for indoor electrical environments.

The Eaton xPole series is engineered for versatility, safety, and durability, making it ideal for electrical distribution in industrial, commercial, and residential settings requiring DC circuit protection.

DIN rail mounting with removable clip for installation flexibility. Toggle switch reset actuator with visual contact position indicator. Instantaneous break time for effective circuit protection. Rated at 32A current with Type D tripping characteristic.

10 kA breaking capacity compliant with IEC/EN 60898-1 standard. Compact design dimensions: 80 mm width, 75 mm depth. Explore the full range of Miniature Circuit Breakers from Eaton on EnvMart for reliable electrical safety solutions.
