Carlo Gavazzi Monitoring Relay 1 Phase SPDT DIN Rail 48 V ac 115 V ac 230 V ac PIB02CB23150MV

Carlo Gavazzi PIB02CB23150MV Monitoring Relay is a 1-phase single-pole double-throw (SPDT) device designed for industrial and electrical automation systems requiring precise overvoltage and overcurrent detection. It supports AC supply voltages of 48 V, 115 V, and 230 V, making it versatile for various power environments.

This relay mounts easily on standard DIN rails, allowing convenient integration in control panels and systems. The device features adjustable measuring ranges selectable via DIP switches, including 2 to 20 VAC/DC and 5 to 50 VAC/DC, with programmable latching functions and adjustable voltage limits on a relative scale to tailor sensitivity according to application requirements.

The built-in latch function ensures the ON-position of the relay output is maintained after activation. The red LED clearly signals alarm conditions and power supply status, enhancing diagnostics and system monitoring. Galvanic separation of the power supply enhances system safety and isolates measurement circuits from potential disturbances.

The relay comes equipped with screw-type terminal connections for secure wiring and supports a time delay adjustable from 1 to 6 seconds to prevent nuisance tripping in transient conditions. Its compact form factor of 94 mm length, 80 mm height, and 36 mm width suits compact industrial control setups.

Compliant with international standards including RoHS, CE, UL EN 61000-6-2, EN 61000-6-3, and IEC 60947, this relay ensures reliability and safety compliance in demanding industrial, manufacturing, water treatment, HVAC, and electrical automation scenarios.

Operates with 48 V AC, 115 V AC, and 230 V AC supply voltages. Mounts easily on DIN rail for convenient installation. SPDT contact configuration suitable for single-phase monitoring. Adjustable time delay ranging from 1 to 6 seconds for response tuning.

Equipped with red LED for alarm status indication. Galvanically separated power supply improves safety and reliability. Suitable for undercurrent and overcurrent current sensitivity applications. Compact size with dimensions 94 mm length, 80 mm height, and 36 mm width.

Compliant with RoHS, CE, UL EN 61000-6-2, EN 61000-6-3, IEC 60947 standards. Manufactured in Italy with high-quality components.

This Carlo Gavazzi Monitoring Relay is ideal for industrial electrical control and automation tasks requiring accurate detection of voltage irregularities and current anomalies. Its robust design and compliance with international standards make it suitable for heavy-duty applications in industrial manufacturing plants, HVAC systems, water treatment facilities, and electrical distribution boards.
