Eaton xEffect Miniature Circuit Breaker, 2-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 102183 FAZ-D5/2-NA

Eaton 102183 FAZ-D5/2-NA miniature circuit breaker is a high-quality device designed for use in electrical control panels to provide reliable overcurrent protection. This 2-pole MCB supports a current rating of 5 A with Type D tripping characteristics, making it suitable for circuits with high inrush currents such as motors and transformers. It is rated for 415V AC voltage and can safely interrupt fault currents up to 10 kA, ensuring system safety and integrity.

This breaker features a DIN rail mount for easy installation and a toggle switch actuator with a trip-free design that prevents manual override of the breaker’s protective function. The device uses a thermal magnetic tripping mechanism that combines precise overload and instantaneous short circuit protection. The toggle can be sealed in both ON and OFF positions, enhancing safety and maintenance operations.

With an IP20 ingress protection rating, it guards against solid objects greater than 12 mm and provides basic protection against electrical contact. The unit’s compact dimensions - 105 mm wide and 76 mm deep - facilitate installation in dense control panel environments. Screw-type terminals ensure secure and reliable electrical connections. Visual red and green indicator lights display contact status for easy troubleshooting.

The FAZ series by Eaton represents a versatile and dependable family of Miniature Circuit Breakers suitable for industrial, commercial, and manufacturing applications, providing effective short circuit and overload protection. This specific model serves as supplementary protection in electrical distribution setups.

Equipped with 2 poles and a 5A current rating suitable for control panel circuits. Type D tripping curve supports high inrush currents of inductive loads. Rated AC voltage of 415V and breaking capacity of 10 kA ensures operational safety.

DIN rail mounting simplifies installation and replacement in existing setups. Thermal magnetic tripping mechanism for reliable differential protection. Toggle switch actuator with trip-free design prevents manual tampering.

Sealable toggle switch enhances circuit security and maintenance safety. Screw terminals offer secure wiring connections and durability. Compact dimensions enable space-efficient panel layouts. IP20 rating provides basic protection against contact and ingress of foreign objects.

Visual indicators show breaker status clearly for operational monitoring.

For industries requiring reliable electrical protection devices, Eaton’s 102183 FAZ-D5/2-NA provides trusted performance complying with industrial standards without approvals listed. Browse our wide range of circuit breakers at EnvMart for tailored industrial electrical solutions.
