Eaton xEffect Miniature Circuit Breaker, 3-Pole, 15A Current Rating, Type D Tripping Characteristics, 415V 278895 FAZ-D15/3

Name: Eaton xEffect Miniature Circuit Breaker, 3-Pole, 15A Current Rating, Type D Tripping Characteristics, 415V 278895 FAZ-D15/3
Brand: Eaton
SKU: 381411
Price: 154.09 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Eaton Condition New

Specifications

Country of Origin	India
Range	xEffect
Brand	Eaton
Model	278895 FAZ-D15/3
Depth	73mm
IP Rating	IP20
Width	85mm
Mount Type	DIN Rail
Current Rating	15A
Series	xEffect
Terminal type	Twin-Purpose Terminal
Breaking Capacity	10kA
Number of Poles	3
Rated AC Voltage	415V ac
Tripping Characteristics	Type D
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous

Key Features

Designed for DIN rail mounting in control panel applications.
Type D tripping characteristic for high inrush current tolerance.
Thermal-magnetic tripping mechanism ensures six levels of over-current protection.
10 kA breaking capacity suitable for industrial and commercial electrical circuits.
Toggle switch actuator offers easy and safe manual operation.
Compact dimensions of 85mm width and 73mm depth for space-efficient installation.
IP20 rated for protection against solid objects but no water protection.
Red or green indicator shows the contact position clearly.

Product Description

Eaton 278895 FAZ-D15/3 Miniature Circuit Breaker delivers high reliability and safety in electrical protection applications. This 3-pole MCB with a 15 amp current rating and Type D tripping characteristics is rated for 415V AC operation and features a breaking capacity of 10 kA, which is suitable for both industrial and commercial environments.

Designed for control panel use, this device mounts easily on DIN rails and fits compactly with dimensions of 85mm width and 73mm depth. Its thermal-magnetic trip mechanism provides six levels of over-current protection, ensuring excellent response to electrical faults while minimizing let-through energy damage.

The toggle switch actuator enables straightforward manual operation, and the device offers visual indication of contact position via red or green indicators. With an IP20 rating, it is protected against intrusion of solid foreign objects.

This circuit breaker complies with Eaton's xEffect series standards and offers supplementary protection with instantaneous break time. Its trip-free design ensures safe operation by preventing manual override of the trip mechanism. This MCB is ideal for applications in electrical automation, industrial manufacturing, commercial buildings, and laboratory environments requiring reliable circuit protection.

Designed for DIN rail mounting in control panel applications. Type D tripping characteristic for high inrush current tolerance. Thermal-magnetic tripping mechanism ensures six levels of over-current protection. 10 kA breaking capacity suitable for industrial and commercial electrical circuits.

Toggle switch actuator offers easy and safe manual operation. Compact dimensions of 85mm width and 73mm depth for space-efficient installation. IP20 rated for protection against solid objects but no water protection. Red or green indicator shows the contact position clearly.

Suitable for supplementary protection with instantaneous break time. Reliable and safe operation with a trip-free design preventing manual defeat. Explore the broad Eaton xEffect range and find more reliable Miniature Circuit Breakers at EnvMart to meet your industrial and commercial electrical protection needs.
