Eaton xEffect Miniature Circuit Breaker 2-Pole 8A Type C 415V AC 10 kA Breaking Capacity 102166 FAZ-C8/2-NA
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 102166 FAZ-C8/2-NA |
| Depth | 76mm |
| IP Rating | IP20 |
| Width | 105mm |
| Mount Type | DIN Rail |
| Current Rating | 8A |
| Series | xEffect |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- The breaker has a thermal magnetic tripping mechanism for accurate protection.
- It is designed for DIN rail mounting in control panel applications.
- The device supports current limiting design to reduce short circuit damage.
- Toggle switch actuator with trip-free design ensures safety and reliability.
- Rated for 2 poles and a current rating of 8 amperes.
- Equipped with screw terminals and IP20 ingress protection.
- The breaker dimensions are 105mm width and 76mm depth.
- Instantaneous break time provides fast response during faults.
Product Description
Eaton 102166 FAZ-C8/2-NA Miniature Circuit Breaker is a 2-pole device designed for use in electrical control panels and automation systems. Rated at 8 amperes and characterized by type C tripping characteristics, it operates efficiently at 415V AC with a high breaking capacity of 10 kA, ensuring robust protection against overload and short circuit conditions.
This breaker features a thermal magnetic trip mechanism, combining six levels of over-current protection for enhanced safety. The current limiting design minimizes let-through energy during faults, protecting connected equipment from damage.
The toggle switch allows for quick manual operation with a trip-free design that prevents the breaker from being held in the ON position, enhancing operational safety. Screw-type terminals facilitate secure wiring connections, and the product is mountable on DIN rails for standardized panel installations.
Its compact dimensions, measuring 105mm in width and 76mm in depth, make it suitable for tight panel spaces. The device is also rated IP20 for ingress protection, appropriate for standard electrical enclosures.
Eaton's xEffect series circuit breakers, including this model, are well-suited for industrial, electrical distribution, HVAC applications, manufacturing, and commercial electrical systems. The reliable and safe operation makes it a preferred choice in industrial automation and electrical safety environments.
The breaker’s thermal magnetic tripping mechanism provides precise control and safety. Rated for 2 poles and 8 Amps current capacity with type C characteristic. High breaking capacity rated at 10 kA to handle short circuit events.
DIN rail mountable design ensures easy integration into electrical panels. Toggle switch with trip-free design enables safe manual operation. Screw terminal type for secure and reliable electrical connections. Compact dimensions suitable for dense panel layouts.
IP20 rating offers protection against solid objects.
Set your electrical systems up with Eaton’s trusted Miniature Circuit Breaker solutions available in the xEffect product range. Explore more industrial circuit breakers and electrical protection devices at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Eaton xEffect Miniature Circuit Breaker has a breaking capacity of 10 kA, providing robust protection against short circuit conditions.
This model is rated for a current of 8 amperes, suitable for various electrical applications.
It operates efficiently at a rated AC voltage of 415V, making it suitable for industrial and commercial electrical systems.
This circuit breaker is a 2-pole device, designed for use in electrical control panels and automation systems.
It features a thermal magnetic tripping mechanism, which provides accurate protection against overload and short circuit conditions.
The dimensions of this model are 105mm in width and 76mm in depth, making it compact for tight panel spaces.
It is equipped with screw-type terminals, ensuring secure and reliable electrical connections during installation.
Yes, this model is designed for DIN rail mounting, facilitating easy integration into electrical control panels.
This breaker has an IP20 ingress protection rating, suitable for standard electrical enclosures.
It has Type C tripping characteristics, which are designed for applications with moderate inrush currents.
The reset actuator type is a toggle switch, which allows for quick manual operation and includes a trip-free design for enhanced safety.
This model is well-suited for industrial, electrical distribution, HVAC applications, manufacturing, and commercial electrical systems.
