Bourns 1038 Shielded Wirewound Surface Mount Inductor with Carbonyl Powder Core 2.2 μH ±20 % 12 A Idc Q:20 SRP1038A

Free Delivery in India | Lowest Global Shipping Charges

Bourns 1038 Shielded Wirewound Surface Mount Inductor with Carbonyl Powder Core 2.2 μH ±20 % 12 A Idc Q:20 SRP1038A

Name: Bourns 1038 Shielded Wirewound Surface Mount Inductor with Carbonyl Powder Core 2.2 μH ±20 % 12 A Idc Q:20 SRP1038A
Brand: BOURNS
SKU: 377198
Price: 1.13 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	3.8mm
Length	11mm
Model	SRP1038A
Depth	10mm
Packaging	Reel
Series	SRP1038A
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-40°C
Core Material	Carbonyl Powder
Inductance	2.2μH
Standards/Approvals	RoHS
Package/Case	1038
Maximum DC Current	12A
Pin Count	2
Maximum DC Resistance	7mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	25MHz
Minimum Quality Factor	20
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

Maximum DC current rating of 12 A suitable for power applications.
Compact 1038 package case with dimensions 11 mm length, 3.8 mm height, and 10 mm depth.
Rated for operating temperatures from -40°C to 150°C with RoHS compliance.
Wirewound construction with magnetic shielding for reduced EMI.
High-quality factor minimum of 20 and a maximum DC resistance of 7 mΩ.
Terminated with solder style for reliable PCB mounting.
Automotive standard AEC-Q200 qualification ensures durability in automotive systems.

Product Description

Bourns SRP1038A 1038 Shielded Wirewound Surface Mount Inductor with Carbonyl Powder Core offers 2.2 μH inductance with a tolerance of ±20 % and a maximum DC current of 12 A. Designed for power and automotive electronics, this inductor features a magnetically shielded wirewound construction for minimized EMI and high performance.

The 1038 package case measures 11 mm in length, 3.8 mm in height, and 10 mm in depth, making it suitable for compact PCB designs. The carbonyl powder core provides a high saturation current capacity and stability across operating temperatures ranging from -40°C to 150°C.

With a maximum DC resistance of 7 mΩ and a minimum quality factor of 20, the SRP1038A is optimized for high efficiency in power supply circuits, DC/DC converters, and automotive applications such as driver assistance, information, entertainment, and lighting systems. It is AEC-Q200 rated for automotive reliability and RoHS compliant for environmental safety.

The termination style is solder type, ensuring robust and secure mounting on printed circuit boards. The inductor supports frequencies up to 25 MHz with an effective self-resonant frequency for efficient filtering and energy storage.

Maximum DC current of 12 A for high power handling. Compact 1038 package with 11 mm length and 3.8 mm height. Wirewound with shielding to reduce interference. Supports operating temperatures from -40°C to 150°C. Carbonyl powder core for high stability and saturation current.

Automotive grade AEC-Q200 certified for system reliability. RoHS compliant for environmental standards. This inductor is ideal for industrial, automotive, consumer electronics, and power supply manufacturing applications where compact, high-performance inductors are required.
