Bourns 5040 Shielded Wirewound Surface Mount Inductor 10 μH ±20% 2.1 A Idc Ferrite Core SRN5040

Free Delivery in India | Lowest Global Shipping Charges

Bourns 5040 Shielded Wirewound Surface Mount Inductor 10 μH ±20% 2.1 A Idc Ferrite Core SRN5040

Name: Bourns 5040 Shielded Wirewound Surface Mount Inductor 10 μH ±20% 2.1 A Idc Ferrite Core SRN5040
Brand: BOURNS
SKU: 375906
Price: 0.3 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	4mm
Length	5mm
Model	SRN5040
Depth	5mm
Packaging	Reel
Series	SRN5040
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance Range	1.5 to 47 μH
Inductance	10μH
Standards/Approvals	RoHS
Package/Case	5040
Maximum DC Current	2.1A
Pin Count	2
Maximum DC Resistance	68mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	17MHz
Minimum Quality Factor	17
Inductor Construction	Wirewound

Key Features

Features a semi-shielded construction with ferrite core for enhanced magnetic performance.
Compact 5040 package size with dimensions 5 mm length, 4 mm height, and 5 mm depth.
Maximum DC resistance of 68 mΩ and operates across a temperature range from -40°C to 125°C.
Supports a maximum self-resonant frequency of 17 MHz and a minimum quality factor of 17.
Wirewound inductor designed for solder termination style and supplied in reel packaging for automated assembly.
Suitable for applications including DC/DC converters, notebooks, digital video cameras, HDDs, cellphones, televisions, and LCD displays.
Compliant with RoHS environmental standards and molded for durability.

Product Description

Bourns SRN5040 Shielded Wirewound Surface Mount Inductor, with a ferrite core, offers an inductance of 10 μH ±20% and supports a maximum DC current of 2.1 A. This Surface Mount Inductor is designed in a compact 5040 package measuring 5 mm in length, 4 mm height, and 5 mm depth, making it optimal for space-constrained electronic designs.

The semi-shielded construction provides reduced electromagnetic interference, enhancing performance in sensitive electronic circuits. The wirewound inductor incorporates a ferrite core and features solder termination style, making it compatible with automated PCB assembly processes.

Operating effectively over a wide temperature range from -40°C to 125°C, and with a maximum DC resistance of 68 mΩ, this inductor ensures reliability and stability. It has a high maximum self-resonant frequency of 17 MHz and meets or exceeds RoHS compliance for environmental safety.

This product is ideal for industrial and commercial electronics applications, including DC/DC converters, notebook computers, digital video cameras, hard disk drives, cellphones, televisions, and LCD displays. The reel packaging supports efficient manufacturing workflows by allowing easy feeding into automated placement machinery.

Features a semi-shielded construction that minimizes electromagnetic interference. Compact package dimensions of 5 mm length, 4 mm height, and 5 mm depth ensure space efficiency. Ferrite core material enhances inductance performance and stability.

Rated for a maximum DC current of 2.1 A and maximum DC resistance of 68 mΩ. Operating temperature range from -40°C to 125°C supports diverse environmental conditions. High self-resonant frequency of 17 MHz ensures suitability for high-frequency circuits.

Compliant with RoHS standards and equipped with molded construction for durability.

This Bourns SRN5040 inductor is an essential component in modern electronic devices requiring reliable power inductance and efficient surface mount packaging. Browse the Electronics & Electricals category on EnvMart for more high-quality passive components available for industrial applications.
