TE Connectivity Shielded Wirewound Surface Mount Inductor 1812 Package 220 μH ±10% 100 mA DC Current Ferrite Core 3613C221K

TE Connectivity 3613C221K is a shielded wirewound surface mount inductor featuring a ferrite core, designed for electronic applications requiring precise inductance with stable performance.

This 1812 package size inductor has an inductance of 220 μH with a tolerance of ±10%, capable of handling up to 100 mA DC current. It is engineered to operate reliably within a temperature range of -30°C to +100°C, making it suitable for various industrial and electronic environments.

The inductor's compact dimensions of 4.5 mm length, 3.2 mm height, and 3.2 mm depth facilitate integration into dense PCB layouts. A maximum DC resistance of 10 ohms ensures low power loss. The device also features a high minimum quality factor (Q) of 40 and a maximum self-resonant frequency of 4 MHz, ensuring effective filtering and energy storage in electronic circuits.

Shielding reduces electromagnetic interference (EMI), improving circuit reliability in sensitive electronic devices. Its wirewound construction provides precision inductance stability, ideal for applications ranging from communication equipment to power supplies.

The inductor is molded and RoHS compliant, confirming adherence to environmental standards and mechanical durability. It is designed for surface mount technology (SMT) assembly, with a two-pin termination style suitable for automated processes.

Ferrite core wirewound construction for high performance. Shielded design reduces electromagnetic interference. Compact 1812 package size for space-saving PCB layouts. Rated for 220 μH inductance with ±10% tolerance. Operates from -30°C up to 100°C for versatile applications.

100 mA maximum DC current capacity ensures reliable operation. Maximum DC resistance of 10 ohms minimizes power loss. High quality factor (Q) of 40 and 4 MHz resonant frequency. RoHS compliant and molded for environmental and mechanical robustness.

These features make the TE Connectivity 3613C221K surface mount inductor suitable for industrial electronics, communication devices, medical instrumentation, and other advanced electronic manufacturing requirements. Browse EnvMart for more high-quality inductors and compatible components.
