onsemi DC Input Optocoupler Through Hole 6-Pin MDIP TIL117M

onsemi TIL117M is a DC input optocoupler featuring a phototransistor output and through-hole mounting in a 6-pin MDIP package. It is engineered for applications requiring electrical isolation and signal transmission in industrial, electronic, and power control systems.

This device provides a maximum forward voltage of 1.4 V with a maximum input current of 3 A, allowing efficient operation and reliable switching. Its high isolation voltage rating of 7500 V AC ensures user and equipment safety by preventing high voltage transients from passing through.

The TIL117M operates effectively across a temperature range of -40°C to 100°C, suitable for harsh environments. It delivers a consistent current transfer ratio of 50%, ensuring predictable signal amplification and integrity.

Typical rise and fall times are 2 microseconds each, supporting applications requiring fast response times.

Designed for through-hole assembly, the 6-pin MDIP package facilitates integration into printed circuit boards with ease. The product meets EN, IEC, and UL standards, guaranteeing compliance with widely recognized safety and quality requirements.

Widely used in industrial automation, power supplies, control circuits, and electronic signal isolation, onsemi TIL117M is a reliable component for improving system safety and performance.

This product is supplied in tubes, convenient for automated insertion equipment and volume manufacturing processes. Designed for DC input current operation with high isolation voltage. Provides a phototransistor output with a fast 2μs typical rise and fall time.

Maximum forward voltage of 1.4 volts to ensure efficient operation. High isolation voltage rating of 7500 V AC for industrial safety. Operates over a wide temperature range from -40°C to 100°C. Compact 6-pin MDIP package suitable for through-hole mounting.

Typical maximum input current of 3 amperes for robust signal control. Maximum and minimum current transfer ratio both at 50% for stable performance. Conforms to standards from EN, IEC, and UL for quality assurance. This optocoupler is from the TIL series and is not automotive rated.
