Phoenix Contact SMSTB 2.5/5-ST-5.08 Series Pluggable Terminal Block, 5-Contact, 5.08 mm Pitch, 1 Row 1826319

Phoenix Contact 1826319 is a high-quality SMSTB 2.5/5-ST-5.08 series pluggable terminal block featuring 5 contacts with a 5.08 mm pitch and a single row configuration. It is engineered to provide reliable and efficient electrical connections in industrial and electronic equipment requiring compact and robust terminal solutions.

The terminal block supports a continuous current of 12 amperes and accommodates wire sizes ranging from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG), making it versatile for various electrical installation requirements. The housing is made of polyamide material, offering excellent resistance to mechanical and thermal stresses.

With a voltage rating of 320 V and a screw connection using a tension sleeve, this terminal block ensures secure and stable wire connections. Its green color coding facilitates easy identification during installation and maintenance.

The unit dimensions are 25.6 mm in width, 25.4 mm in length, and 15.5 mm in depth, allowing it to fit compactly onto printed circuit boards or DIN rail mount systems. Its straight orientation and single-row design are optimized for tight installation spaces, permitting operation and conductor connections from one direction only.

This product enables connecting two conductors per terminal, benefiting from a maximum contact force that minimizes temperature rise during operation, enhancing reliability and longevity of the electrical connection.

The terminal block supports a current rating of 12A for reliable power transmission. It accommodates wire sizes from 0.2 mm² to 2.5 mm², corresponding to 24 AWG to 12 AWG. The housing is constructed from durable polyamide material, ensuring mechanical and thermal robustness.

It has a green color and uses a screw connection with tension sleeve for secure wiring. The product measures 25.6 mm in width, 25.4 mm in length, and 15.5 mm in depth for compact PCB mounting. Designed with a straight orientation and a single row for streamlined installation.

Voltage rating is up to 320 V, suitable for a wide range of electronic applications. Allows connection of two conductors with maximum contact force minimizing temperature rise. Optimized for tight installation situations with operation and conductor connection accessible from one direction.

This pluggable terminal block is ideal for industrial automation, electronic assembly, electrical distribution, control panels, and signal processing applications, providing a dependable and maintainable connection solution. The German-made product meets high standards of quality and performance to ensure long-term reliability in demanding environments.
