Phoenix Contact MSTB 2.5/8-ST-5.08 BD:1-8 Series Pluggable Terminal Block, 8-Contact, 5.08 mm Pitch, 1 Row 1758393

Phoenix Contact 1758393 Series Pluggable Terminal Block provides reliable connection for electronic and industrial applications requiring secure and compact wiring solutions.

This 8-contact female terminal block is designed for use on printed circuit boards with a pitch of 5.08 mm and arranged in a single row for efficient layout. Manufactured with a durable polyamide housing, it withstands demanding industrial conditions ensuring longevity and mechanical stability.

The connection method is a screw connection with a tension sleeve, allowing for a secure and vibration-resistant wire attachment supporting wires sized from 0.2 mm² up to 2.5 mm² (24 to 12 AWG). The terminal block is rated for 12 ampere current and 320 volts, suitable for a wide range of control and power distribution tasks.

Its right angle configuration and compact dimensions of 18.3 mm length, 35.56 mm width, and 15 mm depth allow space-efficient PCB designs. The copper alloy contacts ensure optimum electrical conductivity and minimal contact resistance, reducing heat generation and enhancing reliability.

The component meets UL 94 V0 flammability rating, which means it self-extinguishes quickly enhancing safety in industrial setups. Operating temperature range from -40°C to +100°C makes it suitable for harsh environments in automation, manufacturing, and electronics assembly.

Polyamide housing for mechanical strength and durability. Eight female contacts arranged in a single row with 5.08 mm pitch. Screw connection with tension sleeve for secure, vibration-resistant wiring. Supports wire sizes 0.2 mm² to 2.5 mm² (24 to 12 AWG).

Rated for 12 A nominal current and 320 V voltage. Compact right angle design saves PCB space. Copper alloy contacts deliver efficient electrical conduction. Flammability rating V0 according to UL 94 for safety. Temperature range -40°C to +100°C for harsh environments.

This Phoenix Contact MSTB 2.5/8-ST-5.08 BD:1-8 terminal block is ideal for industrial electronics, automation systems, power connectors, and PCB wiring applications requiring reliability and durability. Check other compatible products and accessories in the Pluggable Terminal Block category on EnvMart for your industrial and commercial needs.
