TE Connectivity AMPMODU MOD II Series Straight Through Hole PCB Socket, 6-Contact, 2 Row, 2.54 mm Pitch, 12A 5-534206-3
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket features a straight through hole mount design compatible with 2.54 x 2.54 mm centerline spacing.
- Housing is made from durable Liquid Crystal Polymer supporting high temperature up to 105°C.
- The contacts are female, made of bronze and gold plated for reliable connectivity.
- Supports a maximum voltage of 750V and minimum operating temperature of -65°C.
- This AMPMODU MOD II connector is end stackable with closed entry housings to prevent post damage.
- Termination is through soldering ensuring strong mechanical and electrical connection.
- Ideal for board-to-board interconnects in automation and control applications.
- The connector system offers a compact, economical solution suitable for industrial electronic assemblies.
Product Description
TE Connectivity 5-534206-3 AMPMODU MOD II Series Straight Through Hole PCB Socket features 6 female contacts arranged in two rows with a 2.54 mm pitch. Rated for 12A current and 750V voltage, this connector is designed for reliable board-to-board connections in demanding industrial environments.
The socket housing is constructed from high-quality Liquid Crystal Polymer which enables operation at temperatures ranging from -65°C to 105°C. The contacts themselves are bronze with gold plating to ensure optimal conductivity and corrosion resistance.
The AMPMODU MOD II receptacle assembly is end stackable with closed entry housings to protect contacts from damage during handling and assembly. Mount type is through hole, offering robust mechanical stability on the printed circuit board.
This connector series is widely used in automation and control system applications where signal integrity and durability are critical. Its compact design and standardized 2.54 mm pitch make it compatible with a variety of industrial connectors and systems.
The socket features a straight through hole mount design compatible with 2.54 x 2.54 mm centerline spacing. Housing is made from durable Liquid Crystal Polymer supporting high temperature up to 105°C. The contacts are female, made of bronze and gold plated for reliable connectivity.
Supports a maximum voltage of 750V and minimum operating temperature of -65°C. This AMPMODU MOD II connector is end stackable with closed entry housings to prevent post damage. Termination is through soldering ensuring strong mechanical and electrical connection.
Ideal for board-to-board interconnects in automation and control applications. The connector system offers a compact, economical solution suitable for industrial electronic assemblies.
This product is intended for use across a range of industrial and manufacturing sectors including automation systems, electronic equipment fabrication, laboratory instrumentation, and power connectors for embedded electronics.
Explore the comprehensive range of PCB Sockets and power connectors available through EnvMart for high quality TE Connectivity products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB socket is 750V.
This connector has a current rating of 12A.
The housing is made from Liquid Crystal Polymer, while the contacts are made of bronze and gold plated for conductivity.
The pitch size of the contacts in this model is 2.54 mm.
The minimum operating temperature is -65°C, and the maximum operating temperature is 105°C.
Termination for this socket is done through soldering, ensuring a strong mechanical and electrical connection.
This connector has a total of 6 female contacts arranged in two rows.
This socket supports a through hole mounting type.
Yes, this connector is designed for board-to-board interconnects, particularly in automation and control applications.
The orientation of this connector is straight.
This product is manufactured in China.
The connector system type for this model is board-to-board.
