Murata Wirewound Surface Mount Inductor 12 nH ±2 % 500 mA Idc 0402 Package with Ferrite Core LQW15AN12NG00D

Murata LQW15AN12NG00D wirewound surface mount inductor with ferrite core is engineered for high-frequency circuits requiring precision inductance values and stable performance. This 0402 package inductor delivers 12 nanohenries (nH) of inductance with a tight tolerance of ±2 % to ensure accuracy in sensitive electronic assemblies.

The device supports a maximum DC current rating of 500 mA, making it suitable for low power applications. Its ferrite core construction offers superior magnetic characteristics while maintaining a molded design for mechanical stability. With a height of 0.5 mm and depth of 0.6 mm, the component fits efficiently in compact circuit designs.

Boasting a minimum quality factor (Q) of 30 and a maximum self-resonant frequency reaching up to 5.5 GHz, this inductor efficiently handles high-frequency signals and minimizes energy losses. The maximum DC resistance of 140 milliohms contributes to energy efficiency and thermal reliability.

This surface mount inductor is RoHS compliant, endorsing environmentally responsible manufacturing practices. The solder termination style facilitates straightforward PCB assembly. Its operational temperature spans from -55°C to 125°C, ensuring optimal functionality under various climatic conditions.

Ideal for industrial applications such as wireless telecommunications including Bluetooth, GSM, and WLAN equipment, these inductors enhance high-frequency circuit performance. The packaging includes paper tape designed for easy automated production line use.

Compact 0402 package size. 12 nH inductance with ±2 % tolerance. 500 mA maximum DC current rating. Ferrite core construction. High quality factor of 30 minimum. Maximum self-resonant frequency of 5.5 GHz. RoHS compliant and solder termination style.

Operational temperature range from -55°C to 125°C.

This Murata LQW15AN12NG00D inductor is suitable for use in industrial, telecommunications, and high-frequency electronic applications. Explore more such high-quality Surface Mount Inductors in the Electronics & Electricals category at EnvMart for enhanced circuit design and performance.
