onsemi 150 V 20 A Schottky Diode 3-Pin Through Hole TO-220FP MBRF20H150CTG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 16.12mm |
| Length | 10.63mm |
| Model | MBRF20H150CTG |
| Width | 4.9mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-220FP |
| Minimum Operating Temperature | -20°C |
| Standards/Approvals | UL 94 V-0, Pb Free, RoHS |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 30mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 180A |
| Maximum Forward Voltage Vf | 870mV |
Key Features
- Maximum continuous forward current of 20 A ensures robust performance under load.
- Peak reverse repetitive voltage of 150 V supports high voltage capability.
- Rectifier type is Schottky, providing low forward voltage drop and high efficiency.
- Compact TO-220FP package with 3 pins designed for through-hole mounting.
- Operating temperature range from -20°C to 150°C suits a wide variety of environments.
- Peak forward surge current rating of 180 A for transient load handling.
- Low peak reverse current of 30 mA reduces leakage losses.
- Compliant with UL 94 V-0, Pb Free, RoHS standards for reliability and environmental safety.
Product Description
onsemi MBRF20H150CTG is a 150 V, 20 A rated Schottky diode housed in a 3-pin TO-220FP through-hole package. This device provides efficient rectification with a low forward voltage drop of 870 mV, making it ideal for power supplies and fast switching applications.
The diode features a peak reverse repetitive voltage (Vrrm) of 150 V, allowing it to withstand high voltage stress. With a maximum continuous forward current of 20 A and a peak non-repetitive forward surge current (Ifsm) of 180 A, it is suited for demanding transient and steady-state conditions.
It operates reliably in temperatures ranging from -20°C to 150°C. The low peak reverse current of 30 mA helps minimize leakage losses, enhancing system efficiency. Physical dimensions length 10.63 mm, width 4.9 mm, and height 16.12 mm allow compact PCB integration.
This diode is compliant with UL 94 V-0 flame retardant standards and is RoHS and Pb Free certified, ensuring environmental compliance and safety.
The MBRF20H150CTG is widely used in industrial, power electronics, and electronic component assemblies where high efficiency and reliability are required. Its through-hole mounting facilitates easy replacement and prototyping in laboratory and manufacturing environments.
Maximum continuous forward current of 20 A ensures robust performance under load. Peak reverse repetitive voltage of 150 V supports high voltage capability. Rectifier type is Schottky, providing low forward voltage drop and high efficiency.
Compact TO-220FP package with 3 pins designed for through-hole mounting. Operating temperature range from -20°C to 150°C suits a wide variety of environments. Peak forward surge current rating of 180 A for transient load handling.
Low peak reverse current of 30 mA reduces leakage losses. Physical dimensions: length 10.63 mm, width 4.9 mm, height 16.12 mm. Compliant with UL 94 V-0, Pb Free, RoHS standards for reliability and environmental safety. Non-automotive standard component suitable for power electronics and industrial use.
Explore more components like the onsemi MBRF20H150CTG and related Schottky diodes on EnvMart for your industrial and electronic design projects.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 20 A, ensuring robust performance under load.
It operates reliably in temperatures ranging from -20°C to 150°C, making it suitable for a wide variety of environments.
The diode is housed in a TO-220FP package and is designed for through-hole mounting with 3 pins.
The peak forward surge current rating for this model is 180 A, which is suitable for transient load handling.
The maximum forward voltage drop is 870 mV, contributing to its efficiency in rectification applications.
It is compliant with UL 94 V-0, Pb Free, and RoHS standards, ensuring reliability and environmental safety.
The physical dimensions of this diode are 10.63 mm in length, 4.9 mm in width, and 16.12 mm in height.
This model is widely used in industrial, power electronics, and electronic component assemblies where high efficiency and reliability are required.
The Schottky rectifier type provides a low forward voltage drop, enhancing efficiency in power supply and fast switching applications.
The diode configuration is common cathode, which is typical for Schottky diodes.
