Bourns 1060 Shielded Wirewound Surface Mount Inductor with Ferrite Core 33 μH ±20% 3.15A Idc Q:16 SRN1060

Free Delivery in India | Lowest Global Shipping Charges

Bourns 1060 Shielded Wirewound Surface Mount Inductor with Ferrite Core 33 μH ±20% 3.15A Idc Q:16 SRN1060

Name: Bourns 1060 Shielded Wirewound Surface Mount Inductor with Ferrite Core 33 μH ±20% 3.15A Idc Q:16 SRN1060
Brand: BOURNS
SKU: 368116
Price: 0.67 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	China
Brand	Bourns
Height	6mm
Length	9.8mm
Model	SRN1060
Depth	10mm
Packaging	Reel
Series	SRN1060
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	33μH
Standards/Approvals	RoHS
Package/Case	1060
Maximum DC Current	3.15A
Pin Count	2
Maximum DC Resistance	72mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	7MHz
Minimum Quality Factor	16
Inductor Construction	Wirewound

Key Features

Features a ferrite core for improved magnetic performance.
Designed with shielding to minimize electromagnetic interference.
Compact 1060 package with 9.8mm length, 6mm height, and 10mm depth dimensions.
Suitable for high-frequency applications up to 7 MHz with a quality factor of 16.
Rated for operating temperatures from -40°C to 125°C for versatile use.
Wirewound construction ensures robust and stable inductance.
Termination style is solder for easy PCB mounting.
Manufactured to RoHS standards ensuring environmental compliance.

Product Description

Bourns SRN1060 shielded wirewound surface mount inductor with ferrite core is designed for reliable inductance performance of 33 μH ±20% and supports a maximum DC current of 3.15 A. This component features a semi-magnetically shielded construction reducing electromagnetic interference, suitable for demanding electronic designs in industrial and commercial electronics sectors.

This miniature 1060 series inductor measures 9.8mm in length, 6mm in height, and 10mm in depth, providing a compact footprint ideal for space-constrained surface mount assemblies. Its ferrite core and wirewound construction deliver stable inductance and low DC resistance of 72 mΩ, ensuring efficient power handling.

With a self-resonant frequency of 7 MHz and a quality factor of 16, the SRN1060 is optimized for power inductors used in DC/DC converters, notebook computers, digital video cameras, televisions, and LCD display applications. The inductor is rated for operation between -40°C and 125°C and meets RoHS environmental standards.

Termination uses solder style allowing straightforward PCB mounting. The device is supplied on a reel packaging ideal for automated assembly processes, enhancing production efficiency. The SRN1060 series is manufactured in China and represents a reliable choice for industrial electronic component applications requiring shielded inductors.

Features a ferrite core for improved magnetic performance. Designed with shielding to minimize electromagnetic interference. Compact 1060 package with 9.8mm length, 6mm height, and 10mm depth dimensions. Suitable for high-frequency applications up to 7 MHz with a quality factor of 16.

Rated for operating temperatures from -40°C to 125°C for versatile use. Wirewound construction ensures robust and stable inductance. Termination style is solder for easy PCB mounting. Manufactured to RoHS standards ensuring environmental compliance.

Ideal for DC/DC converters, notebooks, digital video cameras, and LCD displays. Packaged on a reel for efficient assembly processing. Explore the Bourns range of Surface Mount Inductors and related electronic components at EnvMart for industrial, commercial, and electronic design needs.
