Eaton DR Shielded Surface Mount Inductor with Ferrite Core 100 μH ±20 % 990 mA Idc DR74-101-R

Free Delivery in India | Lowest Global Shipping Charges

Eaton DR Shielded Surface Mount Inductor with Ferrite Core 100 μH ±20 % 990 mA Idc DR74-101-R

Name: Eaton DR Shielded Surface Mount Inductor with Ferrite Core 100 μH ±20 % 990 mA Idc DR74-101-R
Brand: Eaton
SKU: 367447
Price: 1.14 USD
Availability: InStock



Category Surface Mount Inductors Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	4.35mm
Length	7.6mm
Model	DR74-101-R
Depth	7.6mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	100μH
Standards/Approvals	RoHS
Package/Case	0704
Maximum DC Current	990mA
Pin Count	2
Maximum DC Resistance	383mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

This surface mount inductor features a 0704 package case style with dimensions 7.6 mm length, 4.35 mm height, and 7.6 mm depth.
It has a wide operating temperature range from -40°C to 125°C suitable for demanding environments.
The inductor utilizes a wirewound construction on a ferrite magnetic core to ensure magnetic shielding and high efficiency.
Maximum DC resistance is 383 milliohms, with an inductance tolerance of ±20% and maximum self-resonant frequency of 100 kHz.
Designed for applications such as DC-DC converters, noise filtering, buck and boost converters, LCD panels, and portable electronic devices.
This component complies with RoHS environmental standards and is packaged on reels for production efficiency.
Ideal for industrial electronics, power supplies, and telecommunications equipment requiring compact shielded inductors.

Product Description

Eaton DR74-101-R is a shielded surface mount inductor designed with a ferrite core and wirewound construction. With a nominal inductance of 100 μH and a maximum DC current rating of 990 mA, it provides efficient energy storage and noise filtering in compact electronic circuits.

This inductor features a 0704 package case with physical dimensions of 7.6 mm length, 4.35 mm height, and 7.6 mm depth. It supports a wide operating temperature range from -40°C to 125°C, making it suitable for harsh industrial and commercial environments.

The device offers a maximum DC resistance of 383 milliohms and an inductance tolerance of ±20%, ensuring reliable performance in DC-DC converters, buck, boost, forward, and resonant converter topologies. Its maximum self-resonant frequency is 100 kHz, optimizing operation in power supply and filtering applications.

The robust ferrite core provides magnetic shielding to minimize interference, improving overall circuit stability. The surface mount termination style enables automated PCB assembly and space-efficient designs.

Typical applications include computers, DVD players, portable devices, LCD panels, telecommunications, and power management systems. The component is RoHS compliant and supplied on reels for seamless integration in mass production.

This surface mount inductor uses a ferrite core for high magnetic efficiency and shielding. Inductance of 100 μH with a tolerance of ±20% ensures design flexibility. Maximum DC current of 990 mA supports medium power applications.

Operating temperature from -40°C to 125°C suits industrial use cases. Wirewound construction and surface mount termination enhance reliability and PCB mounting. Maximum DC resistance of 383 mΩ helps maintain low power loss.

RoHS compliant and molded for durability under various conditions.

This Eaton surface mount inductor DR74-101-R is engineered for efficient power filtering and energy storage in electronic systems used in industrial, commercial, and telecommunications sectors. Browse EnvMart for more Surface Mount Inductors and related components for your design needs.
