Eaton Wirewound Shielded Surface Mount Inductor 6.8 μH ±20% 3.12 A Idc Ferrite Core 0703 Package DR73-6R8-R

Free Delivery in India | Lowest Global Shipping Charges

Eaton Wirewound Shielded Surface Mount Inductor 6.8 μH ±20% 3.12 A Idc Ferrite Core 0703 Package DR73-6R8-R

Name: Eaton Wirewound Shielded Surface Mount Inductor 6.8 μH ±20% 3.12 A Idc Ferrite Core 0703 Package DR73-6R8-R
Brand: Eaton
SKU: 367444
Price: 1.07 USD
Availability: InStock



Category Surface Mount Inductor Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	3.55mm
Length	7.6mm
Model	DR73-6R8-R
Depth	7.6mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	6.8μH
Standards/Approvals	RoHS
Package/Case	0703
Maximum DC Current	3.12A
Pin Count	2
Maximum DC Resistance	43.5mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

This inductor is designed for surface mount technology with a 0703 package case size.
It offers magnetic shielding to reduce electromagnetic interference.
The inductance tolerance is ±20%, ensuring consistency for circuit designs.
Maximum DC resistance is 43.5 milliohms, optimizing efficiency in power circuits.
Operating temperature range spans from -40°C to 125°C for reliable performance.
The device is constructed with a wirewound coil on a ferrite core providing high power density.
It supports maximum self-resonant frequency of 100 kHz suitable for noise filtering applications.
Packaged on a reel for efficient automated assembly and production.

Product Description

Eaton DR73-6R8-R Wirewound Shielded Surface Mount Inductor is a high efficiency passive component designed for modern electronics applications. It incorporates a ferrite core and a wirewound design that delivers 6.8 μH inductance with a tolerance of ±20%. Rated for a maximum DC current of 3.12 A, this inductor is optimized for use in power electronics where compact size and reliable filtering are essential.

Its surface mount 0703 package case allows integration on densely populated PCB layouts, fulfilling space-saving requirements in electronics manufacturing. Magnetic shielding minimizes electromagnetic interference making it suitable for sensitive circuitry.

The component operates safely in temperatures ranging from -40°C to 125°C, ensuring stable performance across diverse environmental conditions. With a maximum DC resistance of 43.5 milliohms, it reduces power losses and improves overall system efficiency.

This inductor finds common use cases in computers, DVD players, LCD panels, and portable devices, particularly within DC-DC converters and noise filtering circuits like buck, boost, forward, and resonant converters. Packaged on a reel, it supports automated insertion and production line efficiency.

This device complies with RoHS standards. Core material is ferrite and the construction is wirewound for effective inductance. Maximum self-resonant frequency of 100 kHz enables it to handle high-frequency noise filtering.
