Eaton DR127-221-R Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20 % 2.43 A Idc

Free Delivery in India | Lowest Global Shipping Charges

Eaton DR127-221-R Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20 % 2.43 A Idc

Name: Eaton DR127-221-R Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20 % 2.43 A Idc
Brand: Eaton
SKU: 367436
Price: 1.21 USD
Availability: InStock



Category Surface Mount Inductor Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	8mm
Length	12.5mm
Model	DR127-221-R
Depth	12.5mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	220μH
Standards/Approvals	RoHS
Package/Case	0127
Maximum DC Current	2.43A
Pin Count	2
Maximum DC Resistance	376mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

This inductor features a ferrite core construction for effective magnetic shielding.
It has a ±20% inductance tolerance suitable for varied electronics applications.
Compact surface mount termination style promotes PCB integration.
Maximum operating temperature is 125°C ensuring thermal reliability.
Reel packaging aids efficient manufacturing insertion processes.
The inductor supports a maximum DC resistance of 376 mΩ.
Designed with a wirewound construction providing high power density and efficiency.
Operates with a maximum self-resonant frequency of 100 kHz.

Product Description

Eaton DR127-221-R shielded wirewound surface mount inductor with ferrite core provides 220 μH inductance and a maximum DC current capacity of 2.43 A, suitable for advanced electronics applications.

Featuring a magnetically shielded ferrite core and wirewound construction, this inductor ensures high power density and efficiency in compact surface mount form.

The device is manufactured to operate reliably at temperatures up to 125°C and offers a ±20% inductance tolerance, making it ideal for noise filtering, DC-DC converters, and power conditioning circuits in computers, DVD players, LCD panels, and portable devices.

Its termination style is surface mount with a 2-pin configuration and comes in 12.5 mm length, 8 mm height, and 12.5 mm depth dimensions. The inductor has a maximum DC resistance of 376 mΩ and a self-resonant frequency up to 100 kHz.

Packaged on reels for automated insertion processes, it supports efficient manufacturing and complies with RoHS environmental standards. This inductor features a ferrite core construction for effective magnetic shielding.

It has a ±20% inductance tolerance suitable for varied electronics applications. Compact surface mount termination style promotes PCB integration. Maximum operating temperature is 125°C ensuring thermal reliability. Reel packaging aids efficient manufacturing insertion processes.

The inductor supports a maximum DC resistance of 376 mΩ. Designed with a wirewound construction providing high power density and efficiency. Dimensions include 12.5 mm length, 8 mm height, and 12.5 mm depth. Operates with a maximum self-resonant frequency of 100 kHz.

Meets RoHS standards for environmental compliance. This product is highly recommended for industrial, commercial electronics manufacturing, and applications requiring reliable magnetic shielding and power inductors. Explore the extensive range of Surface Mount Inductors at EnvMart for premium components and solutions.
