Eaton Non-Resettable Time Delay Fuse, Radial 3.15A, 250V ac Plastic Body SS-5-3-15A-BK

Free Delivery in India | Lowest Global Shipping Charges

Eaton Non-Resettable Time Delay Fuse, Radial 3.15A, 250V ac Plastic Body SS-5-3-15A-BK

Name: Eaton Non-Resettable Time Delay Fuse, Radial 3.15A, 250V ac Plastic Body SS-5-3-15A-BK
Brand: Eaton
SKU: 367245
Price: 1.14 USD
Availability: InStock



Category Non-Resettable Fuse Brand Eaton Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Diameter	0.6mm
Brand	Eaton
Body Material	Plastic
Height	8.35mm
Length	8.5mm
Model	SS-5-3-15A-BK
Width	4.3mm
Current Rating	3.15A
Series	SS5
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Lead Length	4.3mm
Breaking Capacity	35A
Standards/Approvals	VDE, RoHS, UL 94V0, IEC 600680
Fuse Characteristics	Time Delay
Lead Orientation	Radial
Eaton Non-Resettable Fuse, Radial 3.15A, 250V acBrand	Eaton

Key Features

The fuse body is constructed from durable plastic ensuring electrical insulation and mechanical stability.
It features a small rectangular-leaded design to minimize PCB space usage.
The fuse provides a breaking capacity of 35 amps, suitable for low breaking requirements.
Operating temperature ranges from -40°C to 125°C for versatile application environments.
Lead length is 4.3 mm with a diameter of 0.6 mm, optimized for secure PCB mounting.
Fuse characteristics include time delay to withstand transient surges without nuisance blowing.
The fuse meets standards including VDE, RoHS compliance, UL 94V0 flammability, and IEC 600680 series.
It is part of the SS5 series from Eaton, formerly known as Cooper Bussmann.

Product Description

Eaton SS-5-3-15A-BK is a non-resettable time delay fuse featuring a radial lead orientation for efficient printed circuit board (PCB) mounting. This fuse is rated for 3.15 amps at 250 volts AC, designed to protect electrical circuits by interrupting unexpected overloads and short circuits.

The fuse body uses high-quality plastic material providing strong electrical insulation and resistance to environmental impacts. It has compact dimensions of 8.5 mm in length, 4.3 mm width, and 8.35 mm height, which conserves valuable PCB real estate.

The 4.3 mm lead length with 0.6 mm diameter ensures reliable mechanical and electrical connections. Its time delay characteristic permits temporary surges without blowing prematurely, thus offering stable protection in fluctuating operational environments.

With a maximum operating temperature of 125°C and minimum of -40°C, this fuse offers robust temperature tolerance suitable for industrial, electrical, and automation applications.

Its breaking capacity of 35 amps supports low breaking current scenarios, complying with stringent safety and performance standards such as VDE, RoHS, UL 94V0, and IEC 600680 series. The Eaton SS5 series fuse is well-suited for industrial electronics, HVAC controls, automation circuits, and power distribution systems in manufacturing environments.

The fuse body is constructed from durable plastic ensuring electrical insulation and mechanical stability. Small rectangular-leaded design minimizes PCB space utilization. Breaking capacity of 35 amps supports low breaking scenarios.

Operating temperature range from -40°C to 125°C for varied environment use. Lead length and diameter optimized for reliable PCB mounting. Time delay characteristics to tolerate transient surges without nuisance trips. Compliant with VDE, RoHS, UL 94V0, and IEC 600680 standards.

Part of the Eaton SS5 series, ideal for industrial and automation applications.

This Eaton Non-Resettable Fuse is a reliable choice for protecting electrical circuits in industrial, manufacturing, electrical automation, HVAC, and laboratory equipment. Its robust construction and time delay feature ensure safety and durability in demanding applications.
