Eaton Non-Resettable Fast Acting Electrical Fuse Radial Lead 5A 250V AC SR-5F-5A-BK

Free Delivery in India | Lowest Global Shipping Charges

Eaton Non-Resettable Fast Acting Electrical Fuse Radial Lead 5A 250V AC SR-5F-5A-BK

Name: Eaton Non-Resettable Fast Acting Electrical Fuse Radial Lead 5A 250V AC SR-5F-5A-BK
Brand: Eaton
SKU: 367244
Price: 1.36 USD
Availability: InStock



Category Non Resettable Fuse Brand Eaton Condition New

Specifications

Country of Origin	India
Voltage	250V ac
Diameter	8.5mm
Brand	Eaton
Body Material	Plastic
Height	8.1mm
Length	7.6mm
Model	SR-5F-5A-BK
Width	8.5mm
Current Rating	5A
Series	SR-5F
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Lead Length	4.3mm
Breaking Capacity	50A
Standards/Approvals	UL, UL 4814, MILSTD0F, IEC 600680, UL 94V0, RoHS
Lead Diameter	0.6mm
Fuse Characteristics	Fast Acting
Lead Orientation	Radial

Key Features

The fuse features a fast-acting characteristic suitable for PCB protection.
It has a radial lead orientation enabling easy installation on circuit boards.
Constructed with a thermoplastic polyamide body, ensuring durability and safety.
Designed to operate within -40°C to 125°C temperature range.
Offers a breaking capacity of 50A to protect circuits effectively.
The lead length measures 4.3mm with a 0.6mm lead diameter for precision connections.
Complies with standards including UL, UL 4814, MILSTD0F, IEC 600680, UL 94V0, and RoHS.
Eaton SR-5F-5A-BK fuse is ideal for electrical automation and circuit protection applications.

Product Description

Eaton SR-5F-5A-BK non-resettable fuse is a fast acting electrical fuse designed for industrial and automation use, featuring a radial lead and a current rating of 5A at 250V AC. The fuse body is made of thermoplastic polyamide to ensure robust performance and safety compliance.

This fuse operates efficiently in a temperature range of -40°C to 125°C and has a breaking capacity of 50A, suitable for protecting sensitive electronics and circuits from fault conditions.

The fuse dimensions are compact with a length of 7.6mm, width of 8.5mm, height of 8.1mm, and 4.3mm lead length, making it suitable for PCB mounting. The lead diameter of 0.6mm ensures secure electrical connections.

Designed for industrial, laboratory, and commercial electrical automation and circuit protection applications, it meets strict quality standards including UL, MILSTD, IEC, and RoHS certifications for reliability and safety.

The fuse exhibits a fast-acting characteristic for rapid protection. Radial lead orientation simplifies installation on printed circuit boards. Durable thermoplastic polyamide body ensures long-lasting operation. Temperature rated from -40°C to 125°C for wide environmental applications.

High breaking capacity of 50A allows effective fault interruption. Compact form factor with precise lead dimensions enhances compatibility. Conforms to UL, MILSTD0F, IEC 600680, UL 94V0, and RoHS standards. Formerly marketed under Cooper Bussmann SR-5F series known for quality fuse solutions.

This fuse is ideal for use in electrical automation systems, industrial control panels, and other electrical circuit protection roles requiring dependable fast-acting fuse protection.
