Weidmüller BC 3.81 Series 6-Contact Pluggable Terminal Block 3.81 mm Pitch 320V 17.5A 1 Row Nylon Housing 1798590000

Name: Weidmüller BC 3.81 Series 6-Contact Pluggable Terminal Block 3.81 mm Pitch 320V 17.5A 1 Row Nylon Housing 1798590000
Brand: Weidmuller
SKU: 361775
Price: 20.22 USD
Availability: InStock



Category Pluggable Terminal Blocks Brand Weidmuller Condition New

Specifications

Country of Origin	China
Voltage	320V
Brand	Weidmüller
Colour	Black
Orientation	Right Angle
Current	17.5A
Length	22.86mm
Depth	19.1mm
Width	10.5mm
Housing Material	Nylon
Series	BC 3.81
Number of Rows	1
Pitch	3.81mm
Standards/Approvals	RoHS
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	739-3930 Brand: [Weidmüller](https://in.rsdelivers.com/brands/weidmuller)Manufacturers Part No.: 1798590000
Number of Contacts	6
Connector Gender	Male
Minimum Wire Size mm²	2mm²
Maximum Wire Size mm²	1.5mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Screw

Key Features

Constructed with durable nylon housing for reliable insulation.
Supports currents up to 17.5 A and voltage rating of 320 V.
Features right angle orientation with screw wire connection method.
Compatible with wire sizes from 28 AWG to 16 AWG (0.2 to 1.5 mm²).
Black color for easy identification and integration.
Single row terminal block ideal for industrial and commercial electrical assemblies.
Manufactured according to RoHS standards ensuring environmental compliance.

Product Description

Weidmüller 1798590000 BC 3.81 Series pluggable terminal block features 6 contacts with a 3.81 mm pitch and a single row configuration, designed for versatile industrial and commercial electrical connection applications. The terminal block is constructed with a robust nylon housing that provides excellent electrical insulation and mechanical durability.

Engineered to support currents up to 17.5 A and a voltage rating of 320 V, this component ensures reliable performance in power distribution and control systems. The device employs a screw clamp wire connection method that facilitates secure and maintenance-friendly wiring.

The terminal block accommodates wire sizes from 28 AWG to 16 AWG (0.2 to 1.5 mm²), offering flexibility to fit various conductor sizes. Its right angle orientation makes it suitable for PCB mounting where space and accessibility are considerations.

Compact dimensions of 22.86 mm length, 10.5 mm width, and 19.1 mm depth enable integration into tight electrical assemblies while maintaining safe spacing between contacts.

Compliant with RoHS standards, this terminal block contributes towards environmentally responsible product design and usage. The black coloration aids in component identification and aesthetic consistency in electrical panels.

Durable nylon housing ensures electrical insulation and longevity. Supports high current applications up to 17.5 A and voltage up to 320 V. Screw clamp connection provides strong and secure wire terminations. Suitable wire size range from 28 AWG to 16 AWG (0.2 to 1.5 mm²).

Right angle design optimized for PCB mounting. Compact size for use in constrained spaces. RoHS compliant for environmental safety. Ideal for industrial, manufacturing, and commercial electrical applications requiring pluggable connectors.

This product is an essential component in electrical distribution, control cabinets, and industrial automation systems, offering dependable connectivity and ease of maintenance. Explore a wide range of Weidmüller products and Pluggable Terminal Blocks in EnvMart's Electronics & Electricals category for professional and commercial use.
