Wurth Elektronik 353 Series Pluggable Terminal Block, 2-Contact, 5.08 mm Pitch, 1 Row 691353500002

Wurth Elektronik 691353500002 is a high-quality 353 Series pluggable terminal block designed for reliable electrical connections in industrial, automation, and electronic systems. This 2-contact terminal block features a 5.08 mm pitch and a single-row configuration, optimized for space-efficient PCB layouts and straightforward wiring applications.

The connector incorporates a green polyamide housing with a UL94-V0 rating, ensuring excellent flame retardance and durable insulation. The stainless steel wire guard enhances mechanical stability and secure wire retention without requiring screws, using a screwless push-in design for rapid and maintenance-free installation.

It supports wire sizes ranging from AWG 26 (0.13 mm² minimum) to AWG 12 (3.31 mm² maximum), accommodating a wide range of conductor diameters. Rated for a continuous current of 10A and an operating voltage of 300V AC, this terminal block is suitable for control panels, industrial machinery, and other electrical applications requiring robust and safe wire connections.

The compact dimensions (length 10.16 mm, width 24.1 mm, depth 15.1 mm) allow it to fit within tight PCB assemblies or mechanical enclosures. The straight orientation aids in straightforward cable entry and routing. This series is manufactured in China under the trusted Wurth Elektronik brand, ensuring consistent quality and conformity with industry standards.

This product is ideal for engineers and technicians designing power connectors and terminal blocks for electronic and electrical device assemblies where reliability and safety standards are paramount.

Features a green polyamide housing with UL94-V0 flame retardant rating. Supports wire sizes from AWG 26 to AWG 12 with cable entry wire connection method. Rated for 10A current and 300V AC voltage applications. Compact dimensions with length 10.16 mm, width 24.1 mm, and depth 15.1 mm.

Designed with a straight orientation and stainless steel wire guard for secure connections. Housing material provides insulation and mechanical protection. Suitable for use in industrial electronics and electrical control systems.

Manufactured in China, part of Wurth Elektronik's 353 series terminal blocks. Explore more electronic components and connectors from Wurth Elektronik at EnvMart for your industrial and manufacturing needs.
