Weidmüller BC 3.81 Series Pluggable Terminal Block 2-Contact 3.81 mm Pitch 320V 17.5A Screw Connection Nylon 1798780000
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 17.5A |
| Length | 18.04mm |
| Depth | 12.5mm |
| Width | 10.5mm |
| Housing Material | Nylon |
| Series | BC 3.81 |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 739-3946 Brand: [Weidmüller](https://in.rsdelivers.com/brands/weidmuller)Manufacturers Part No.: 1798780000 |
| Number of Contacts | 2 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screw |
Key Features
- Designed with a robust nylon housing ensuring durability.
- Supports a maximum current rating of 17.5A for efficient power handling.
- Operates at a voltage rating of 320V suitable for various applications.
- Features a screw connection method for secure wire fastening.
- Right angle orientation simplifies PCB layout and connectivity.
- Compatible with wire sizes ranging from 28 AWG to 16 AWG (0.2 to 1.5 mm²).
- Complies with RoHS standards ensuring environmental safety.
Product Description
The Weidmüller 1798780000 BC 3.81 Series Pluggable Terminal Block is an industrial-grade connector designed for secure and reliable electrical connections in various electronic applications. Featuring 2 contacts spaced at a 3.81 mm pitch and housed in durable black nylon, this terminal block is engineered to handle currents up to 17.5A at 320V.
Its screw-based connection mechanism provides dependable wire retention suitable for wire sizes between 0.2 mm² and 1.5 mm², or 28 AWG to 16 AWG, making it versatile for a wide range of wiring configurations. The connector’s right-angle orientation is optimized for efficient PCB mounting and space conservation.
Compact in size, with dimensions of 18.04 mm in length, 10.5 mm in width, and 12.5 mm in depth, this terminal block fits neatly into dense electronic assemblies. It conforms to RoHS directives, ensuring it meets environmental compliance standards.
This terminal block is suited for industrial, commercial, and electronic manufacturing applications where reliable power and signal connections are critical. For mating components, refer to Weidmüller Omnimate series with 3.81 mm pitch headers.
Robust nylon housing for durability and safety. Screw clamp connection to secure wires firmly. Supports 17.5A current at 320V voltage rating. Right angle design to optimize PCB layout. Compatible with 0.2 mm² to 1.5 mm² wire sizes (28-16 AWG).
Compact dimensions reduce board space usage. RoHS compliant for environmentally safe manufacturing. Explore related products in our Pluggable Terminal Blocks category for expanded connectivity solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a maximum current rating of 17.5A, making it suitable for efficient power handling in various applications.
The voltage rating is 320V, allowing it to handle a range of electrical applications safely.
The contacts are spaced at a pitch of 3.81 mm, which is standard for many applications requiring pluggable connections.
It utilizes a screw connection method, ensuring secure wire fastening for reliable electrical connections.
The dimensions are 18.04 mm in length, 10.5 mm in width, and 12.5 mm in depth, making it compact for PCB layouts.
The housing is made from durable nylon, which contributes to its robustness and safety in various applications.
It features a right-angle orientation, optimizing PCB layout and connectivity in tight spaces.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements.
This model has 2 contacts, allowing for dual connections in a compact design.
It is suited for industrial, commercial, and electronic manufacturing applications where reliable power and signal connections are critical.
