STMicroelectronics Voltage Output Temperature Sensor, Analogue, Through Hole Mount, ±1°C Accuracy, 3-Pin TO-92, MCP9509CT
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±1°C |
| Brand | STMicroelectronics |
| Height | 5mm |
| Length | 5mm |
| Model | MCP9509CT |
| Width | 4mm |
| Mount Type | Through Hole |
| Output type | Voltage |
| Series | MCP9509CT |
| Maximum Operating Temperature | 100°C |
| Package Type | TO-92 |
| Sub Type | Temperature Sensor |
| Minimum Operating Temperature | -40°C |
| Interface Type | Analogue |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 714-7917PBrand: STMicroelectronicsManufacturers Part No.: LM335AZ |
| Pin Count | 3 |
| Maximum Supply Voltage | 3.91V |
| Minimum Supply Voltage | 2.95V |
| Sensor Gain | 10mV/K |
Key Features
- The sensor has a 3-pin TO-92 package suitable for easy through-hole installation.
- It offers a sensor gain of 10mV/K with an output voltage linearly proportional to absolute temperature.
- Operates within a temperature range from -40°C to 100°C for versatile applications.
- Supply voltage range is between 2.95V and 3.91V ensuring compatibility with various circuits.
- The compact 5mm x 5mm x 4mm dimension allows integration in space-constrained environments.
- Designed for high reliability with RoHS compliance and no automotive standard certification.
- Ideal for industrial, laboratory, HVAC, manufacturing, and embedded system temperature monitoring tasks.
Product Description
STMicroelectronics MCP9509CT Voltage Output Temperature Sensor, model LM335AZ, is a highly accurate analogue temperature sensor featuring ±1°C accuracy and a 3-pin TO-92 through hole mount package. It produces a linear voltage output of 10mV per Kelvin, acting as a two-terminal zener that delivers an output of 100mV/°K proportional to absolute temperature.
This sensor operates reliably over a broad temperature range from -40°C to 100°C and requires a supply voltage between 2.95V and 3.91V, making it suitable for various electronic applications.
The compact physical dimensions of 5mm length, 5mm height, and 4mm width enable easy integration into circuit boards where space is limited. The device complies with RoHS standards, ensuring environmentally friendly manufacturing without hazardous substances.
With a straightforward analogue interface and through-hole mounting, the MCP9509CT is ideal for industrial, laboratory, HVAC, manufacturing, and embedded systems requiring precise temperature measurement and monitoring.
Key features include high sensitivity with a sensor gain of 10mV/K and robust build quality assuring stable performance without automotive-specific standards. The sensor provides accurate temperature sensing with a ±1°C accuracy rating.
The device supports a broad operating temperature range from -40°C to 100°C. Operates with a supply voltage range of 2.95V to 3.91V for flexible power compatibility. The 3-pin TO-92 package allows easy through-hole mounting on printed circuit boards.
Compact dimensions of 5mm x 5mm x 4mm facilitate applications with space constraints. RoHS compliant manufacturing promotes environmental safety. Linear voltage output simplifies analogue temperature measurement integration.
Equip your system with the STMicroelectronics MCP9509CT sensor for precise and dependable temperature monitoring. Browse more Temperature Sensor solutions at EnvMart to meet your industrial and laboratory requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP9509CT temperature sensor has an accuracy of ±1°C.
This model operates over a temperature range from -40°C to 100°C.
It provides a voltage output that is linearly proportional to absolute temperature, with a gain of 10mV/K.
The dimensions of the MCP9509CT are 5mm in length, 5mm in height, and 4mm in width.
The sensor requires a supply voltage between 2.95V and 3.91V.
This model features a 3-pin TO-92 package suitable for through-hole mounting.
Yes, the MCP9509CT is RoHS compliant, ensuring it is manufactured without hazardous substances.
It is suitable for industrial, laboratory, HVAC, manufacturing, and embedded system temperature monitoring tasks.
The MCP9509CT has a pin count of 3.
The MCP9509CT uses an analogue interface for output.
The sensor gain of the MCP9509CT is 10mV/K.
The MCP9509CT is manufactured in India.
