TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 10 Contacts, 4.14 mm Pitch 1-770971-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 9.5A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Universal MATE-N-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 4.14mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 709-9896PBrand: TE ConnectivityManufacturers Part No.: 1-770971-1 |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.69mm |
Key Features
- Features a 4.14 mm pitch for precise wire-to-board connections.
- Constructed with a durable white UL94V-0 nylon housing for safety and insulation.
- Rated for 600 volts and 9.5 amperes current operation.
- Right angle mount with through hole design enables secure PCB attachment.
- Brass contacts plated with gold ensure reliable conductivity and corrosion resistance.
- Includes a positive locking latch mechanism and board locks for stable mating.
- Tail pin length measures 3.69 mm for secure solder connections.
- Operates reliably under temperatures from -55°C to 105°C.
Product Description
TE Connectivity 1-770971-1 Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header is designed for robust wire-to-board connections in electronic and industrial applications. It features a 4.14 mm pitch and comes with 10 gold-plated brass contacts arranged in 2 rows with right angle orientation.
The housing material is white UL94V-0 rated nylon, ensuring excellent electrical insulation and flame retardancy. The connector includes a positive locking latch mechanism along with board locks to maintain secure mating and PCB retention during mechanical or thermal stress.
Rated for a maximum voltage of 600 volts and current capacity of 9.5 amps, this PCB header supports demanding power and control circuits. The tail pin length is 3.69 mm and optimized for through hole solder mounting onto PCBs for reliable electrical and mechanical connections.
Operational in a wide temperature range from -55°C to 105°C, the header is suitable for harsh environments including industrial, manufacturing, HVAC, and laboratory electronic assemblies. It complies with basic standards though does not have specific certifications.
Features a 4.14 mm pitch for precise wire-to-board connections. Durable UL94V-0 nylon housing with a positive locking latch and board locks. Gold-plated brass contacts for excellent conductivity and corrosion resistance.
Right angle orientation and through hole mount type for stable PCB attachment. Rated for 600V and 9.5A current capacity. Wide operating temperature range from -55°C to 105°C for harsh environments. Ideal for electronic components, power connectors, and PCB assemblies in industrial settings.
This product is categorized under PCB Headers in the Electronics & Electricals Connectors segment at EnvMart. Explore more from TE Connectivity and find complementary connectors and accessories to complete your assembly needs.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a maximum voltage of 600 volts.
This model has a current capacity of 9.5 amperes.
The connector features a pitch of 4.14 mm for precise wire-to-board connections.
It has a total of 10 contacts arranged in 2 rows.
This unit utilizes a through hole mount type for secure PCB attachment.
The housing is made of UL94V-0 rated nylon, and the contacts are brass plated with gold for conductivity and corrosion resistance.
The tail pin length measures 3.69 mm, optimized for solder connections.
It operates reliably within a temperature range of -55°C to 105°C.
Yes, it includes a positive locking latch mechanism and board locks for stable mating.
This model supports a wire-to-board connector system.
Yes, it is designed to operate in harsh environments due to its wide operating temperature range and robust construction.
The country of origin for this product is India.
