TE Connectivity PIDG Insulated Ring Terminal M5 Stud Size 22 AWG 16 AWG Wire Size Red 130660
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Red |
| THICKNESS | 0.79mm |
| Model | 130660 |
| Insulation | Insulated |
| Overall Length | 27.13mm |
| Contact Material | Copper |
| Series | PIDG |
| Maximum Operating Temperature | 105°C |
| Insulation Material | Nylon |
| Standards/Approvals | RoHS |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 0.26mm² |
| Maximum Wire Size mm² | 1.65mm² |
| Minimum Wire Size AWG | 22AWG |
| Maximum Wire Size AWG | 16AWG |
| Outer Ring Diameter | 11.91mm |
| Inner Ring Diameter | 5.21mm |
| Stud Size | M5 |
Key Features
- Constructed from high conductivity copper for optimum electrical performance.
- Insulated with red nylon sleeve for enhanced wire size identification and insulation support.
- Designed to fit M5 stud size with an overall length of 27.13 mm.
- Suitable for wire sizes ranging from 22 AWG (0.26 mm²) to 16 AWG (1.65 mm²).
- Features a copper sleeve inside the barrel to prevent wire fraying and ensure strong crimping.
- Serrated wire barrel offers maximum contact and tensile strength after crimping.
- Colour coded sleeve facilitates easy tooling and wire size identification.
- Operating temperature up to 105°C makes it reliable in demanding environments.
Product Description
TE Connectivity 130660 PIDG insulated ring terminal offers a reliable and uniform crimping solution for electrical connections. Featuring a precision-formed copper body and barrel with serrations inside the wire barrel, it ensures maximum contact and tensile strength. The copper sleeve surrounding the barrel prevents wire fraying while providing improved insulation support. The red nylon outer sleeve aids quick wire size identification and tooling adherence.
This ring terminal is suitable for use with M5 stud sizes and supports wire sizes from 22 AWG (0.26 mm²) to 16 AWG (1.65 mm²), making it versatile across various wiring applications. Its overall length of 27.13 mm provides efficient electrical connectivity with high reliability.
Operating temperature up to 105°C ensures performance in demanding industrial and commercial environments such as instrumentation, control panels, lighting systems, power supplies, transportation equipment, motors, aerospace applications, and lifting equipment. The lead-free tin plating on the copper contact enhances corrosion resistance and durability over time.
TE Connectivity PIDG ring terminals comply with RoHS standards, affirming their environmental safety. The design includes a funnelled wire entry for quick and easy wire insertion during high-speed production processes. Colour-coded insulation sleeves promote fast and accurate wire size identification across various wire gauges.
High conductivity copper body ensures superior electrical performance. Copper sleeve inside barrel for improved wire insulation support. Serrations in wire barrel for maximum contact and tensile strength. Colour coded red nylon sleeve for ease of identification.
Funnelled wire entry for fast, reliable wire insertion. Tin plated contacts provide corrosion resistance. Operating temperature rating up to 105°C. Compliant with RoHS environmental standards. Suitable for M5 stud and wire sizes 22 AWG to 16 AWG.
This Ring Terminal is an excellent choice for industrial, laboratory, construction, manufacturing, transportation, and aerospace electrical applications, offering secure electrical connections with ease of installation. Browse more TE Connectivity products and accessories on EnvMart for comprehensive wiring solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum wire size compatible with this terminal is 16 AWG, which corresponds to 1.65 mm².
The overall length of this ring terminal is 27.13 mm.
This terminal is designed to fit M5 stud sizes.
The terminal features a copper contact with a tin plating for corrosion resistance and is insulated with a red nylon sleeve.
The minimum wire size that can be used with this terminal is 22 AWG, equivalent to 0.26 mm².
The operating temperature for this terminal can reach up to 105°C.
Yes, this terminal complies with RoHS standards, affirming its environmental safety.
The terminal includes serrations inside the wire barrel and a copper sleeve that prevent wire fraying and ensure strong crimping.
The inner ring diameter is 5.21 mm, and the outer ring diameter is 11.91 mm.
This ring terminal is suitable for various applications including instrumentation, control panels, lighting systems, and motors.
The red nylon sleeve is colour-coded to facilitate quick wire size identification and tooling adherence.
This ring terminal is manufactured in India.
