TE Connectivity PCB Power Relay 5V DC Coil 6A Switching Current SPST SNR Series 9-1415067-1

TE Connectivity 9-1415067-1 PCB Power Relay is engineered for efficient switching applications in electrical and automation systems. Featuring a 5V DC coil voltage and a single-pole single-throw (SPST) contact configuration, this power relay supports switching currents up to 6A. Its slim SNR series design, only 5mm thick, is ideal for high-density PCB mounting scenarios, allowing compact and efficient layouts.

The relay boasts a low coil power consumption of 170mW, contributing to energy efficiency in control circuits. Electrical isolation between coil and contacts stands at 4000Vac, ensuring operational safety. The relay contacts are fabricated with silver alloy, promoting excellent conductivity and long service life. Operating smoothly across a broad temperature range from -40°C to +85°C, this relay is suitable for industrial, commercial, and automation applications where reliability is critical.

With a switching AC voltage rating of 400V and switching power capacity of 1.5 kVA, the relay is suitable for a wide range of AC load control tasks. It uses solder terminal types for secure and straightforward PCB mounting. Dimensions of 28mm length, 15mm height, and 5mm width make it compatible with dense PCB environments. Compliance with IEC, REACH, RoHS, VDE, and UL standards ensures that the product meets international quality and safety benchmarks.

The SNR series slim relay with 5mm thickness facilitates compact PCB board design. 170mW coil power ensures high coil sensitivity and low energy consumption. Silver alloy contact material supports enhanced electrical performance and durability.

Wide operating temperature range from -40°C to +85°C for versatile environment use. 4000Vac isolation between coil and contact provides high safety margin. 6A switching current capacity suitable for various electrical switching loads.

PCB mount type with solder terminals enables secure and efficient installation. Dimensions 28mm x 15mm x 5mm allow space-efficient integration on PCBs. Conforms to IEC, REACH, RoHS, VDE, and UL standards for quality assurance.

This TE Connectivity PCB power relay is widely used in industrial automation, laboratory equipment, HVAC systems, manufacturing control panels, and other electrical machinery requiring reliable relay switching performance. Choosing this relay ensures compliance, efficiency, and dependable operation for critical control applications.
