TE Connectivity Rotary Coded DIP Switch PCB Through Hole Polyester Case DR Series DRS1604
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Model | DRS1604 |
| Mount Type | PCB |
| Case Material | Polyester |
| Series | DR |
| Terminal type | Through Hole |
| TE Connectivity Rotary SwitchBrand | TE Connectivity |
Key Features
- The switch provides 16-position hexadecimal or 10-position BCD output for precise digital control.
- Features gold-flashed brass contacts with pin-point sliding pressure for long operating life.
- Equipped with a metal bracket for enhanced PCB mounting support.
- The shaft is 3.2mm in diameter and 19mm in length with a screwdriver slot enabling knobless operation.
- Suitable for applications requiring reliable rotary coded switching on PCB through hole mounts.
- The compact miniature design suits automation, electrical, and industrial control systems.
- Case material is robust polyester ensuring durability in various environments.
- Offers straight or right angle mounting options ensuring versatile installation.
Product Description
TE Connectivity DRS1604 Rotary Coded DIP Switch PCB Through Hole is a miniature rotary switch designed for reliable digital position coding in electronic circuits. Featuring a miniature binary coded rotary design, it outputs either a 16-position hexadecimal (0-9, A-F) or a 10-position BCD output, providing accurate and flexible switching solutions for complex systems.
The switch incorporates gold-flashed brass contacts with a pin-point sliding pressure mechanism, extending the operating life and ensuring consistent electrical performance over time. Supplied with a sturdy metal bracket, it guarantees extra support when mounted on printed circuit boards through the through-hole terminals that facilitate secure fixation.
The shaft diameter measures 3.2mm with a length of 19mm and features a screwdriver slot for direct actuation without needing a knob, although knobs can be fitted if desired. The case is made of durable polyester material, providing resistance to environmental wear and mechanical stress.
This switch is ideal for industrial, electrical, automation, and control applications requiring precise rotary coded switch positions. Its compact miniature size and versatile mounting options, including straight or right-angle configurations, allow flexible integration into PCB designs.
The DR Series switch from TE Connectivity offers a high-quality solution for robust rotary switching needs on printed circuit boards, enhancing device functionality without compromising reliability or durability.
The switch offers 16-position hexadecimal or 10-position BCD coded output. Gold-flashed brass contacts ensure long operating life with low contact resistance. Metal bracket support improves PCB mount stability. Polyester case provides environmental resistance and mechanical durability.
Shaft design allows screwdriver operation or optional knob use. Application in electronics, automation, and industrial control systems. Available in straight or right angle mounting styles for flexible PCB assembly. Explore more Rotary Coded DIP Switches and related components to suit various electronic and industrial automation needs at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The DRS1604 switch provides a 16-position hexadecimal output (0-9, A-F) or a 10-position BCD output for precise digital control.
The case of the DRS1604 rotary switch is made of durable polyester, providing resistance to environmental wear and mechanical stress.
This model supports PCB mounting with through-hole terminals, and it offers both straight and right-angle mounting options for flexible installation.
The shaft of the DRS1604 has a diameter of 3.2mm and a length of 19mm, featuring a screwdriver slot for operation without a knob.
It features gold-flashed brass contacts, which ensure long operating life and low contact resistance for reliable performance.
Yes, the switch is equipped with a metal bracket that enhances stability and support when mounted on printed circuit boards.
This rotary switch is ideal for applications in industrial, electrical, automation, and control systems that require precise rotary coded switching.
The DRS1604 is designed with a screwdriver slot on the shaft, allowing for direct actuation without the need for a knob, although knobs can be fitted if desired.
The DRS1604 belongs to the DR series of rotary coded DIP switches from TE Connectivity.
The DRS1604 switch is manufactured in India.
The switch incorporates a pin-point sliding pressure mechanism in its gold-flashed brass contacts, which helps to extend its operating life.
This model uses through-hole terminals for secure fixation on printed circuit boards.
