HARWIN M22 Series Straight Through Hole PCB Socket, 9-Contact, 1 Row, 2 mm Pitch, 12A Current, 500V Voltage M22-7130942
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M22-7130942 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 9 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket supports a current rating of 12A, suitable for moderate power applications.
- Constructed with a liquid crystal polymer housing for high temperature resistance up to 105°C.
- Features gold plated bronze female contacts ensuring high reliability and conductivity.
- Designed for through-hole mounting on printed circuit boards with a board-to-board connector system.
- Operates reliably in temperature ranges from -25°C to 105°C without performance degradation.
- Compact and durable design supports up to 300 mating cycles for long service life.
- This connector is ideal for use in embedded PCs, motherboards, and large electronic systems.
- Common applications include consumer electronics, industrial monitoring, communications, and drives.
Product Description
The HARWIN M22-7130942 is a high-quality straight through hole PCB socket with 9 female contacts arranged in a single row. Featuring a fine 2 mm pitch and designed for board-to-board connections, this socket offers a reliable solder termination type and robust construction.
The housing is made of UL94V-0 rated liquid crystal polymer, providing excellent thermal resistance and maintaining structural integrity through standard reflow soldering processes. The bronze contacts are gold plated with a dual beam design, enhancing electrical performance and ensuring durability over extensive mating cycles of up to 300 operations.
This M22 series socket supports currents up to 12A and voltages up to 500V, suitable for a variety of electronic components and systems. It operates efficiently across a broad temperature range from -25°C to 105°C, making it adaptable for demanding industrial and commercial electronics environments.
Its compact footprint allows for increased PCB density without compromising reliability, which is critical in applications such as embedded computer systems, industrial monitoring equipment, and communication devices. The through-hole mount type eases PCB assembly and enhances mechanical strength.
Key features include its high current rating, durable materials, and design versatility suitable for consumer electronics, industrial controls, and personal computing devices. This connector sets a standard for reliability and performance in demanding electronic applications.
The socket’s liquid crystal polymer housing offers high temperature resistance and durability. Gold plated bronze contacts provide superior conductivity and reliability. Supports a current rating of 12A and voltage rating of 500V.
Single row configuration with 9 contacts for compact PCB layouts. Through-hole mount method ensures stable mechanical fixing on PCBs. Suitable for embedded PC, industrial monitoring, consumer electronics, and communication applications.
Explore more in our Electronics Components > PCB Sockets category for compatible connectors and related components.
