HARWIN M22 Series Straight Through Hole PCB Socket, 25-Contact, 1 Row, 2 mm Pitch Solder M22-7132542
Specifications
| Country of Origin | Singapore |
|---|---|
| Voltage | 500V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M22-7132542 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 25 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| 25 way 1 row vertical PCB skt,2mm pitchBrand | Harwin |
Key Features
- Industry standard M22 series with a fine 2 mm pitch for high-density PCB applications.
- Made from high temperature Liquid Crystal Polymer housing rated UL94V-0.
- Gold-plated bronze dual beam contacts ensure reliable electrical connection.
- Supports currents up to 12A and voltages up to 500V for robust performance.
- Rated to withstand operating temperatures from -25°C up to 105°C.
- Through-hole mounting suitable for board-to-board connector systems.
- Compact and durable design capable of 300 mating cycles.
- Contact gender is female with straight orientation for easy assembly.
Product Description
HARWIN M22-7132542 PCB Socket is a straight through hole type connector featuring 25 contacts arranged in a single row with a precise 2 mm pitch solder termination. This connector belongs to the M22 series, widely recognized for high-density PCB designs and compact form factor. The socket housing is constructed from UL94V-0 rated Liquid Crystal Polymer, providing excellent thermal resistance and durability during soldering processes.
The contacts are crafted from bronze material with gold plating to ensure superior electrical conductivity and enhanced connector reliability. Rated for 12A current and 500V voltage, this PCB Socket reliably supports demanding electrical and electronic applications. The 1 row, female contact orientation and through-hole mount type make it compatible with board-to-board connector systems commonly used in embedded PCs, motherboards, and industrial electronics.
Designed with ruggedness in mind, the socket withstands operating temperatures ranging from -25°C to 105°C and tolerates up to 300 mating operations, making it ideal for environments requiring durability and long service life. Manufactured in Singapore under strict quality protocols, this connector meets stringent performance and materials standards without specific approvals or certifications listed.
Industry standard 2 mm pitch for compact PCB layouts. Liquid Crystal Polymer housing with high temperature resistance. Gold-plated bronze dual beam contacts for reliable connections. 12A current and 500V voltage ratings for robust electrical performance.
Through-hole, straight orientation mounting for board-to-board integration. Suitable for industrial, communications, consumer electronics, and embedded computing applications.
Experience advanced PCB interconnection solutions with HARWIN M22 series sockets, designed for compactness, reliability, and high-performance electrical connectivity. Browse EnvMart for more HARWIN connectors and electronic components engineered for modern industrial and electronic manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M22-7132542 PCB socket supports a maximum current rating of 12A.
This model is rated for a maximum voltage of 500V.
The contacts in this socket are arranged with a pitch of 2 mm.
The housing is made from Liquid Crystal Polymer, which is rated UL94V-0 for high temperature resistance.
The HARWIN M22-7132542 features 25 contacts arranged in a single row.
It can operate within a temperature range of -25°C to 105°C.
This unit uses through-hole mounting, making it suitable for board-to-board connector systems.
The contact orientation is straight, which facilitates easy assembly.
The contacts are plated with gold to ensure reliable electrical connections.
This connector is suitable for applications in industrial, communications, consumer electronics, and embedded computing.
This model is designed to tolerate up to 300 mating cycles.
It is manufactured in Singapore under strict quality protocols.
