Phoenix Contact Pluggable Terminal Block 9-Contact 5.08 mm Pitch 1 Row 320V 16A Polyamide Housing Female Connector 1110638

Phoenix Contact 1110638 pluggable terminal block is engineered for secure and efficient electrical connectivity in industrial, automation, and electronic applications. This 9-contact female connector features a 5.08 mm pitch and a single row arrangement, optimized for PCB mounting and wiring use cases.

The terminal block housing is manufactured from high-grade polyamide, delivering mechanical stability and resistance against electrical wear. It supports a nominal current of 16 A and voltage ratings up to 320 V, suitable for a wide range of electrical systems.

The push-in connection method facilitates fast, tool-free wire installation, compatible with wire sizes from 2 mm² to 2.5 mm² (AWG 26 to AWG 12). The connector's straight orientation simplifies wiring layouts and reduces design complexity.

An integrated test option allows quick diagnostics without dismantling connections. Clear lever positions provide reliable feedback on clamping status to enhance user confidence during installation and maintenance.

Physical dimensions - width of 60.98 mm, length of 27.37 mm, and depth of 15.39 mm - make this component suitable for space-constrained circuit assemblies. The green color coding improves visual identification and reduces wiring errors.

Certified by cULus Recognised and VDE, the terminal block adheres to rigorous safety and performance standards, ensuring dependable operation in challenging environments. It operates reliably between ambient temperatures of -40 °C and 105 °C, making it ideal for industrial automation, control cabinets, electrical panels, and other demanding electrical applications.

The housing is made of durable polyamide material ensuring robust mechanical and electrical properties. Rated for a nominal current of 16 A and voltage capacity of 320 V for industrial applications. Features a push-in wire connection method with straight orientation for ease of installation.

Compatible with wire sizes ranging from 2 mm² to 2.5 mm² (26 AWG to 12 AWG). Offers quick and convenient testing via integrated test option. Compact dimensions of 60.98 mm width, 27.37 mm length, and 15.39 mm depth enable efficient PCB mounting.

Green colored female connector provides clear lever positions for reliable contact feedback. Certified with cULus Recognised and VDE standards ensuring compliance and safety. Designed for harsh environments with an operating ambient temperature range of -40 °C to 105 °C.

Ideal for applications in industrial automation, manufacturing equipment, HVAC controls, and electrical distribution systems. This component supports modular wiring solutions requiring reliable signal and power transmission with efficient installation and maintenance capabilities.

Explore more Phoenix Contact Pluggable Terminal Blocks and related components on EnvMart for your electronic assembly needs.
