Abracon 24 MHz Surface Mount Crystal ±30 ppm Load Capacitance 20 pF 4-Pin FC5BQCCMC24.0-T1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 1.2mm |
| Length | 5mm |
| Model | FC5BQCCMC24.0-T1 |
| Packaging | Tape & Reel |
| Width | 3.2mm |
| Mount Type | Surface |
| Series | FC5BQ |
| Maximum Operating Temperature | 70°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | 0°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Standard Frequency | 24MHz |
| Load Capacitance | 20pF |
Key Features
- This crystal operates within a temperature range of 0°C to 70°C.
- It features a compact surface mount package with dimensions 5 mm length, 3.2 mm width, and 1.2 mm height.
- The crystal is RoHS compliant, making it suitable for environmentally-conscious designs.
- Designed with a 4-pin configuration and tape & reel packaging for automated PCB assembly.
- Its series designation is FC5BQ with a silver termination finish and resin seal for durability.
- Ideal for use in electronic circuit timing, oscillators, and frequency control applications.
Product Description
Abracon FC5BQCCMC24.0-T1 is a 24 MHz surface mount crystal unit designed for high precision frequency control in electronic circuits. The crystal features a 4-pin surface mount package measuring 5 mm in length, 3.2 mm in width, and 1.2 mm in height, making it highly suitable for compact PCB layouts and automated assembly lines.
This crystal offers a frequency tolerance and stability of ±30 ppm, operating reliably within the temperature range of 0°C to 70°C. It has a load capacitance of 20 pF and a shunt capacitance of 5 pF, supporting accurate oscillator performance. The resin seal and silver termination finish protect it from environmental factors, ensuring long-term stability and durability.
It is RoHS compliant, meeting environmental standards for hazardous substance restrictions. The product is supplied in tape & reel packaging, suitable for high-volume manufacturing processes.
Typical applications include timing circuits, microcontroller oscillators, frequency synthesis, and communication devices in industrial, laboratory, and commercial electronics sectors.
This crystal operates within a temperature range of 0°C to 70°C. Compact 4-pin surface mount package for PCB assembly. Frequency tolerance and stability rated at ±30 ppm for reliable oscillations. RoHS compliant for environmental safety.
Tape & reel packaging supports automated manufacturing. Resin sealed with silver termination finish for durability. Suitable for electronic devices requiring precise frequency control.
EnvMart offers this Abracon crystal unit for reliable performance in various electronic component assemblies. Explore more electronic components and passive devices in our catalog.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this model is 24 MHz, which is essential for high precision frequency control in electronic circuits.
This unit has dimensions of 5 mm in length, 3.2 mm in width, and 1.2 mm in height, making it suitable for compact PCB layouts.
The load capacitance of this crystal is 20 pF, which supports accurate oscillator performance.
It operates reliably within a temperature range of 0°C to 70°C, suitable for various electronic applications.
The product is supplied in tape & reel packaging, which is ideal for automated PCB assembly in high-volume manufacturing processes.
This model features a pin count of 4, which is typical for surface mount configurations.
Yes, it is RoHS compliant, meeting environmental standards for hazardous substance restrictions.
It belongs to the FC5BQ series, which is designed for high precision frequency control applications.
This unit uses a surface mount type, making it compatible with automated assembly processes.
The shunt capacitance is 5 pF, which contributes to its overall performance in frequency control applications.
