KEMET Polypropylene Capacitor 390 nF 5 % Tolerance 1.6 kV DC 650 V AC Through Hole R75TR339050H3J

KEMET R75TR339050H3J polypropylene capacitor is a high-quality, metallized film capacitor designed for precise electronic applications requiring stable capacitance and excellent reliability. Featuring a capacitance of 390 nF and a tolerance of ±5 %, this capacitor operates with a rated DC voltage of 1.6 kV and rated AC voltage of 650 V. Its through hole mounting and radial leads enable secure PCB connections, with a lead pitch of 27.5 mm and 25 mm lead length.

The capacitor's encapsulation in a self-extinguishing, solvent-resistant plastic case with thermosetting resin material provides robust protection for industrial and automotive environments. This model is RoHS compliant and adheres to IEC 60286-2 and AEC-Q200 standards, ensuring it meets industry safety and performance requirements.

Key features include low dissipation factor (0.05%), low equivalent series resistance (8.2 mΩ), and lead-free terminations with self-healing properties, significantly enhancing its operational durability. Rated for a wide temperature range from -55°C to 105°C, it suits applications like silicon controlled rectifiers and resonant circuits that demand stable medium to high current handling and high-frequency performance.

Physical dimensions are compact, measuring 32 mm in length, 18 mm in width, and 33 mm in height, with lead diameter of 0.8 mm facilitating easy integration in a variety of electronic assemblies.

Constructed with metallized polypropylene film ensuring high stability and low loss. Rated for a maximum operating temperature of 105°C suitable for demanding environments. Features through hole mount with 27.5 mm lead pitch and 25 mm lead length for PCB installations.

Encapsulated in a plastic self-extinguishing case providing solvent resistance and durability. Complies with RoHS, IEC 60286-2 standards and AEC-Q200 automotive certification. Low dissipation factor of 0.05% minimizes energy loss during operation.

Lead-free terminations and self-healing capabilities enhance reliability and lifespan. Compact dimensions: length 32 mm, width 18 mm, height 33 mm, with 0.8 mm lead diameter. Ideal for use in silicon controlled rectifiers, resonant circuits, and high-frequency medium to high current applications.

This capacitor is well suited for industrial, automotive, electronic manufacturing, aerospace, power supply, and laboratory applications requiring precise and reliable film capacitors. For enhanced design integration, 3D models and technical documents are available.
