Honeywell Technologies Pin Plunger Micro Switch PCB Terminal 16A 250 V AC SPCO IP40 V19T16-P2Z400
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 27.8mm |
| Model | V19T16-P2Z400 |
| Depth | 15.9mm |
| IP Rating | IP40 |
| Width | 10.3mm |
| Housing Material | Thermoplastic Polybutylene Terephthalate |
| Series | V19 |
| Maximum Operating Temperature | 125°C |
| Contact Configuration | SPCO |
| Actuator Type | Pin Plunger |
| Minimum Operating Temperature | -25°C |
| Terminal type | PCB Terminal |
| Standards/Approvals | cUL, CQC, CSA, ENEC, RoHS, UL |
| Switch Contact Current | 16A |
| Operating Force | 3.92N |
| Mechanical Life | 60Cycles |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Unsealed |
Key Features
- This micro switch uses a pin plunger actuator type for precise actuation.
- The housing is made of durable thermoplastic polybutylene terephthalate for strength.
- It features an IP40 rating suitable for protection against solid objects larger than 1mm.
- Operates reliably within -25°C to 125°C temperature range.
- Contact configuration is SPCO with a 16A current rating at 250 V AC.
- Mechanical life rated for 60 cycles ensuring longevity in use.
- Compact dimensions enable versatile PCB integration (27.8mm length, 15.9mm depth, 10.3mm width).
- Compliance certified with cUL, CQC, CSA, ENEC, RoHS, and UL standards.
Product Description
Honeywell V19T16-P2Z400 pin plunger micro switch with PCB terminal is a high-quality unsealed micro switch designed for cost-effective and reliable operation in electrical and automation systems.
This micro switch is engineered for industrial and commercial applications where precise on/off switching is required. It features a pin plunger actuator type that delivers consistent actuation force of 3.92N suitable for system auxiliary functions and door latching mechanisms.
Constructed with a thermoplastic polybutylene terephthalate housing, it offers robust mechanical durability and resistance to environmental conditions. The device is rated IP40 for dust ingress protection and operates across a wide temperature range of -25°C to 125°C, ensuring stable performance under varying conditions.
Designed for printed circuit board mounting, it comes with PCB terminals providing ease of installation. Rated for 16A contact current at 250 V AC with a single pole change-over (SPCO) contact configuration, this switch fulfills demanding electrical load requirements.
The compact form factor with length 27.8mm, depth 15.9mm, and width 10.3mm allows versatile integration into control panels and electronic devices. Mechanical life is guaranteed for 60 cycles, affirming its reliability over extended periods.
This micro switch meets multiple international certifications including cUL, CQC, CSA, ENEC, RoHS, and UL ensuring compliance for global use. Ideal for industrial, laboratory, manufacturing, and HVAC applications requiring accurate switch operations.
Ensures safe and reliable door latching and interface control for system auxiliary functions.
Choose this Honeywell V19T16-P2Z400 micro switch for consistent performance and certified quality in critical electrical switching applications. Browse more Micro Switches on EnvMart for tailored solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a contact current rating of 16A at 250 V AC.
It operates reliably within a temperature range of -25°C to 125°C.
The switch features an IP40 rating, providing protection against solid objects larger than 1mm.
It uses a pin plunger actuator type for precise actuation.
The dimensions are 27.8mm in length, 15.9mm in depth, and 10.3mm in width.
The mechanical life is rated for 60 cycles, ensuring longevity in use.
The housing is made of thermoplastic polybutylene terephthalate, providing strength and durability.
It is certified with cUL, CQC, CSA, ENEC, RoHS, and UL standards.
It is designed for printed circuit board (PCB) mounting with PCB terminals for ease of installation.
The contact configuration is SPCO (Single Pole Change Over).
The switch requires an operating force of 3.92N for actuation.
This micro switch is suitable for industrial, laboratory, manufacturing, and HVAC applications requiring precise on/off switching.
