TE Connectivity DIN Rail Power Relay 24V AC Coil 12A Switching Current DPDT PT2S7RC4 5-1415074-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 58mm |
| Length | 73.5mm |
| Model | PT2S7RC4 5-1415074-1 |
| Width | 27mm |
| Mount Type | DIN Rail |
| Contact Material | Silver Nickel Alloy |
| Series | PT |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 12A |
| Terminal type | Screw |
| Standards/Approvals | IEC, RoHS, UL, VDE |
| Coil Resistance | 192Ω |
| Coil Voltage | 24V ac |
| Switching AC Voltage | 400V ac |
Key Features
- Equipped with a 24V AC coil for efficient power use.
- Dual Pole Double Throw (DPDT) contact arrangement supports versatile switching.
- Rated for 12A switching current ensuring high load handling capacity.
- Compact design with DIN rail mounting for easy installation.
- Terminal type is screw for secure electrical connections.
- Operates reliably between -40°C to 70°C environment temperatures.
- Silver Nickel Alloy contact material ensures durability and conductivity.
- Complies with IEC, RoHS, UL, and VDE standards for quality and safety.
Product Description
TE Connectivity PT2S7RC4 5-1415074-1 DIN Rail Power Relay features a 24V AC coil with a 12A switching current capacity and DPDT contact configuration, designed for high performance in electrical and automation applications.
This Power Relay supports DIN rail mounting, providing a compact footprint with dimensions of 73.5mm length, 58mm height, and 27mm width, making installation efficient in industrial control panels.
It utilizes silver nickel alloy contacts which deliver excellent conductivity and long-term reliability under load. The relay operates reliably across a wide temperature range from -40°C to 70°C, suitable for various industrial environments.
The interface module package includes the relay, DIN rail socket, module, retainer, and marking tab. Mechanical and electrical indicators help monitor operation status, while coil resistance at 192Ω ensures stable power functionality.
This relay complies with international IEC 61810-1 standards and holds approvals including IEC, RoHS, UL, and VDE certifications, ensuring quality and safety compliance for industrial, manufacturing, HVAC, and automation uses.
Equipped with a 24V AC coil for efficient power use. Dual Pole Double Throw contact configuration allows flexible circuit control. 12A switching current supports various load requirements. DIN rail mounting simplifies panel installation.
Screw terminal type ensures secure and reliable connections. Wide operating temperature range from -40°C to 70°C ensures performance stability. Silver Nickel Alloy contacts improve durability and electrical performance. Compliant with IEC, RoHS, UL, and VDE standards for safety and quality assurance.
Package includes relay, DIN rail socket, module, retainer, and marking tab for complete interface module setup. Explore a broad range of electrical relays and contactors at EnvMart for industrial and commercial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a switching current capacity of 12A, allowing it to handle various load requirements effectively.
It features a Dual Pole Double Throw (DPDT) contact configuration, which supports versatile circuit control.
The relay operates with a coil voltage of 24V AC, ensuring efficient power use.
The relay has dimensions of 73.5mm in length, 58mm in height, and 27mm in width, making it compact for installation.
It operates reliably between -40°C and 70°C, suitable for various industrial environments.
This model uses screw terminals, which provide secure and reliable electrical connections.
The contacts are made from silver nickel alloy, which enhances conductivity and reliability under load.
It complies with IEC, RoHS, UL, and VDE standards, ensuring quality and safety for industrial applications.
The coil resistance is 192Ω, which ensures stable power functionality during operation.
This relay can switch AC voltages up to 400V, making it suitable for various high-voltage applications.
The package includes the relay, DIN rail socket, module, retainer, and marking tab for complete setup.
It is designed for DIN rail mounting, which simplifies installation in control panels.
