Phoenix Contact FKC 2.5/4-ST-5.08-RF Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 1 Row, Screw 1925715

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact FKC 2.5/4-ST-5.08-RF Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 1 Row, Screw 1925715

Name: Phoenix Contact FKC 2.5/4-ST-5.08-RF Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 1 Row, Screw 1925715
Brand: PHOENIX CONTACT
SKU: 333214
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Germany
Voltage	630V
Brand	Phoenix Contact
Colour	Green
Orientation	Straight
Current	12A
Length	25.73mm
Model	1925715
Depth	15mm
Width	33.74mm
Housing Material	Polyamide
Series	FKC 2.5/4-ST-5.08-RF
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	RoHS
Number of Contacts	4
Connector Gender	Female
Minimum Wire Size mm²	0.2mm²
Maximum Wire Size mm²	2.5mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	12AWG
Wire Connection Method	Screw
PCB connector, nominal current	12 A, rated voltage (III/2): 320 V, number of positions: 4, pitch: 5.08 mm, connection method: Push-in spring connection, colour: green, contact surface: Tin, Article with self-locking flange

Key Features

Rated for 12 A nominal current and 630 V voltage for reliable electrical performance.
Constructed from durable polyamide housing providing robust insulation and mechanical strength.
Supports a wire size range from 0.2 mm² to 2.5 mm², compatible with 24 AWG to 12 AWG wires.
Features a screw-type wire connection method for firm and easy wiring.
Orientation is straight and the contacts have tin plating for corrosion resistance.
Designed as a single-row PCB connector with a self-locking flange for secure attachment.
Complies with RoHS standards ensuring environmental safety.
Manufactured in Germany ensuring high quality and reliability.

Product Description

Phoenix Contact 1925715 is a professional-grade pluggable terminal block designed for electronic and electrical applications requiring reliable, secure connections. This model features four contacts arranged in a single row with a 5.08 mm pitch, making it suitable for compact PCB layouts.

The terminal block can handle a nominal current of 12 A and a rated voltage of up to 630 V, ensuring performance under demanding electrical loads. It features a durable polyamide housing which provides excellent insulation and mechanical robustness.

The wire connection employs a screw mechanism, allowing for firm and secure attachment of wires sized from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG). The contacts are tin-plated, enhancing corrosion resistance and ensuring long-term reliability.

With compact dimensions of 33.74 mm width, 25.73 mm length, and 15 mm depth, the terminal block is designed for efficient PCB space utilization. It also includes a self-locking flange to secure the block on the PCB, reducing vibration or accidental disconnections.

The straight orientation and green color simplify identification and integration into electrical panels and devices. The product fully complies with RoHS standards, supporting environmental compliance.

Ideal for industrial automation, electronic manufacturing, control panels, and power distribution systems, this terminal block combines electrical integrity with mechanical durability.

Manufactured in Germany, the Phoenix Contact 1925715 offers high quality and precision for professional use. This product is part of the FKC 2.5/4-ST-5.08-RF series, known for its reliability in pluggable terminal block connectors.

Rated 12 A nominal current and 630 V voltage for dependable electrical performance. Polyamide housing material ensuring durability and insulation. Screw connection method for secure wire termination. Supports wire sizes from 0.2 mm² to 2.5 mm², and 24 AWG to 12 AWG.

Compact footprint suitable for PCB mounting with self-locking flange. Contact surface plated with tin for corrosion resistance. Single row, 4-contact design with 5.08 mm pitch. Green color coding for easy identification.

RoHS compliant for environmental safety. Explore more professional-grade connectors and terminal blocks at EnvMart to meet your industrial and electronic component needs.
