Celduc Solid State Relay, 30 A Load Current, DIN Rail Mount, 480 V AC Load, 24 V DC Control SMCW6151

Celduc SMCW6151 is a high-quality solid state relay designed for industrial and commercial applications requiring reliable switching of AC loads. This model supports a maximum load current of 30 A and can handle load voltages up to 480 V AC. The relay mounts conveniently on a DIN rail, facilitating quick and secure installation within control panels and electrical enclosures.

Control voltage ranges from 1 V DC minimum to 24 V DC maximum, providing flexible control options for automation systems. The device features a zero cross switching function which minimizes electrical noise and surges during switching, improving the longevity and performance of connected equipment.

The relay uses screw terminals for dependable electrical connections and is enclosed with an IP20 rating, providing protection against solid objects while being suitable for indoor environments. It operates across a wide temperature range from -40°C to 100°C, ensuring performance stability in harsh industrial conditions.

Its output type is thyristor, enabling efficient, silent switching ideal for motor control and heating applications. Additionally, Celduc SMCW6151 offers multiple control input possibilities including PNP, NPN, and dry contact, enhancing compatibility with various control devices such as compressors and pressure switches.

Diagnostic features include motor sector diagnostics covering frequency, phase, presence, rotation, and cabling configurations like star or triangle, as well as output diagnostics for motor speed and cabling. The relay is compliant with EAC and CE standards, and it is manufactured in France, ensuring high-quality build standards.

Supports a maximum load current of 30 amperes. Designed for DIN rail mounting for easy installation. Operates with a maximum load voltage of 480 V AC and minimum load voltage of 200 V AC. Control voltage range from 1 V DC to 24 V DC allows flexible control options.

Features zero cross switching function for smooth operation. Employs screw terminal type for secure electrical connections. Robust IP20 rated enclosure provides protection against solid objects. Operating temperature ranges from -40°C to 100°C for diverse environments.

Thyristor output type ensures reliable switching performance. Includes multiple control possibilities: PNP, NPN, and dry contact.

This solid state relay is ideal for use in industrial automation, manufacturing control systems, HVAC equipment, and electrical signal conditioning, providing robust and efficient load switching with advanced diagnostics.
