SIPL Admittance Level Switch 0.2 PF Switching Hysteresis SLA Series
Specifications
| Country of Origin | India |
|---|---|
| Power Consumption | 5 VA approx. |
| Response time | 0.2 second typical. |
| Relay output | One/two set (s) of potential free change over contacts rated at 230V AC 6A 50 Hz for non-inductive loads. |
| Item Code | SLA-Series |
| Mains Voltage (V) | 230 V or 110 V AC (-15% to +10%) 50 Hz| 24 V AC/DC 90 to 260 V AC universal power supply (to be specified while ordering). |
| Housing | Cast Aluminum weather proof back panel/wall mounting. |
| Switching delay | Adjustable from 0.5 to 20 second for probe covered or uncovered |
| Switching Hysteresis | 0.2 PF. typical |
| Cable Entries | 3 No. / 2 No. |
| Indication (Switching) | Red LED for alarm Green LED for normal. |
| Fail-safe mode | Max. or Min. field selectable. |
| Max. Amb. Temp. | -20 C to + 60 C. |
| Indication (sensitivity) | 10 step LED dot/bar display |
| Connection to Probe | Via co-axial screened cable with drain wire |
Key Features
- Excellent Performance
- Light in weight
- Accurate measurement
- Easy and fast installation
Product Description
SIPL Admittance Level Switch 0.2 PF Switching Hysteresis SLA Series, A level switch is an electrical or mechanical method for measuring the level of a liquid, powder, or granule material. Level switches are an essential part of production operations and are used in harsh conditions with extremes in temperature, pressure, and vibrations.
- Rust proof
- Self Diagnosis
- Compact size
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power consumption of the SIPL Admittance Level Switch is approximately 5 VA.
The typical response time for this level switch is 0.2 seconds.
This model can operate in ambient temperatures ranging from -20°C to +60°C.
It features one or two sets of potential-free changeover contacts rated at 230V AC 6A for non-inductive loads.
The switching hysteresis for this model is typically 0.2 PF.
The housing is made of cast aluminum with a weatherproof back panel suitable for wall mounting.
This switch has 3 or 2 cable entries, depending on the configuration.
Yes, it includes a red LED for alarm and a green LED for normal operation, along with a 10 step LED dot/bar display for sensitivity indication.
Yes, the fail-safe mode can be set to either maximum or minimum, depending on the field selection.
The switching delay can be adjusted from 0.5 to 20 seconds for probe covered or uncovered conditions.
