Diaphragm Boot Level Switch
Specifications
| Brand | EIP Enviro |
|---|---|
| Mounting | Internal or external| 16 gauge galvanized mounting plate |
| Operating Temp | Refer Catalogue as varies with model |
| Switch Ratings | 15 Amps @125| 250 or 480 VAC| 1/8 HP @ 125 VAC| HP @ 250 VAC| 1/2 Amp @ 125 VDC| 1/4 Amp @ 250 VDC |
| Approvals | Hazardous Zone approvals available |
| Housing Enclosure | Die cast aluminum |
Key Features
- Reliable point level detection for free flowing dry materials
- Used in bins, vessels and some plugged chute applications
Product Description
A diaphragmor pressureswitch works by activating a sensitive micro-switch when material reaches the level of the switch in the bin. It sends an alert that can be used to start or stop a process or alert to a high, medium, or low-level in the vessel. Commonly used in grain, feed, seed, or other granular material, BinMaster diaphragm switches are offered for either internal or external mounting and can be wired to a light, horn, alarm, or point-level alarm panel to indicate an alert status. The BM series of diaphragm switches provides simple, low-cost point level control with proven, lasting reliability. Designed for use in bins containing non-hazardous or hazardous, free-flowing dry materials, the BM Switches operate by sensing material pressing against the diaphragm switch. When the switch is pressed, it activates a sensitive micro-switch that can be wired to an alarm to start or stop a process or alert to high, medium, or low levels in bins. The switches are offered in six different models, including standard, heavy-duty neoprene, or heavy-duty silicone diaphragm material, and either internal or external mounting options.
- Feed, seed, grain, food, rubber, plastics, light powders, granules, and many other materials
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switch ratings for this model are 15 Amps at 125, 250, or 480 VAC, and it can handle 1/8 HP at 125 VAC and 1/4 HP at 250 VAC.
This diaphragm boot level switch can be mounted internally or externally using a 16 gauge galvanized mounting plate.
The housing enclosure is made of die-cast aluminum, providing a robust structure for the switch.
The operating temperature varies with the model; it is recommended to refer to the catalogue for specific details.
Yes, hazardous zone approvals are available for this diaphragm boot level switch.
The micro-switch activates when material presses against the diaphragm, sending an alert to start or stop a process or indicate high, medium, or low levels in a vessel.
It operates by sensing material pressing against the diaphragm, which activates the micro-switch to signal level changes.
It can be wired to a light, horn, alarm, or point-level alarm panel to indicate an alert status.
The switch is offered in six different models, including standard, heavy-duty neoprene, or heavy-duty silicone diaphragm materials.
It provides reliable point level detection for free-flowing dry materials in bins, vessels, and some plugged chute applications.
The brand of this model is EIP Enviro.
