Microchip Operational Amplifier 10 MHz Gain Bandwidth, 14-Pin SOIC, 5.5V MCP6024-E/SL
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.25mm |
| Length | 8.65mm |
| Model | MCP6024-E/SL |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP6024 |
| Output Current | 30mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.5V |
| GBP - Gain Bandwidth Product | 10MHz |
| Input Bias Current | 1 pA |
| Slew Rate | 7V/μs |
Key Features
- Offers a gain bandwidth product of 10 MHz for high-frequency amplification.
- Includes four amplifier channels in a single package.
- Operates on a supply voltage range of 2.5V to 5.5V.
- Low input bias current of 1 pA ensures minimal signal distortion.
- Compact dimensions with a 14-pin SOIC surface mount package for PCB efficiency.
- Input offset voltage of 500 µV promotes accurate signal processing.
- Maximum output current of 30 mA suitable for various load conditions.
- Wide operating temperature range from -40°C to 125°C for industrial reliability.
Product Description
Microchip MCP6024-E/SL operational amplifier is a high-performance semiconductor device designed to deliver precise amplification in industrial and electronic applications. Featuring a gain bandwidth product of 10 MHz, it operates efficiently over a supply voltage range of 2.5V to 5.5V, ensuring versatility for various circuit designs.
Housed in a compact 14-pin SOIC surface mount package with dimensions of 8.65 mm length, 3.9 mm width, and 1.25 mm height, the device integrates four independent amplifier channels. Its low input bias current of 1 picoampere and input offset voltage of 500 microvolts promote exceptional signal accuracy, ideal for sensitive or low-level signal amplification.
The MCP6024-E/SL supports a maximum output current of 30 milliamperes, allowing it to drive moderate loads without degradation. Designed to withstand operating temperatures between -40°C and 125°C, it suits demanding industrial and manufacturing environments. Although it does not comply with automotive standards, it remains an excellent choice for laboratory, construction electronics, manufacturing, and general-purpose applications.
Offers a gain bandwidth product of 10 MHz for high-frequency amplification. Four channels integrated into a single 14-pin SOIC package. Operates on a supply voltage range of 2.5V to 5.5V. Low input bias current of 1 pA for minimal signal distortion.
Compact surface mount design for efficient PCB space utilization. Input offset voltage of 500 µV for precise signal handling. Maximum output current up to 30 mA for moderate load driving. Wide temperature range: -40°C to 125°C for industrial environments.
RoHS compliant ensuring adherence to environmental standards. Ideal for electronic components, power connectors, amplifiers and comparator applications in industrial and laboratory settings.
This Microchip Operational Amplifier is supplied in a tube, packaged ready for insertion into machinery, thereby enabling improved production efficiency. The product is suited for professional electronics manufacturing, prototyping, and repair activities. Explore additional Microchip semiconductor components and amplifiers at EnvMart for comprehensive project sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP6024-E/SL has a gain bandwidth product of 10 MHz, suitable for high-frequency amplification applications.
It operates efficiently over a supply voltage range of 2.5V to 5.5V.
This model integrates four independent amplifier channels in a single package.
The dimensions are 8.65 mm in length, 3.9 mm in width, and 1.25 mm in height.
The maximum output current is 30 mA, allowing it to drive moderate loads.
It features a low input bias current of 1 picoampere, which helps minimize signal distortion.
The input offset voltage is 500 microvolts, promoting accurate signal processing.
It operates within a wide temperature range of -40°C to 125°C, suitable for industrial environments.
The MCP6024-E/SL is housed in a 14-pin SOIC surface mount package.
Yes, it is RoHS compliant, ensuring adherence to environmental standards.
The slew rate is 7 V/μs, which is relevant for determining the speed of response to changes in input signals.
The MCP6024-E/SL is manufactured in India.
