STMicroelectronics Digital Output Temperature Sensor Series, Surface Mount I2C Interface ±0.5 °C Accuracy, 6-Pin UDFN MCP9701
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | 0.5 °C |
| Brand | STMicroelectronics |
| Height | 550μm |
| Length | 2mm |
| Model | MCP9701 |
| Width | 2mm |
| Mount Type | Surface |
| Output type | Digital |
| Series | MCP9701 |
| Maximum Operating Temperature | 125°C |
| Package Type | UDFN |
| Sub Type | Temperature Sensor |
| Minimum Operating Temperature | -40°C |
| Supply Voltage | 1.5 to 3.6 V |
| Interface Type | I2C |
| Pin Count | 6 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 1.5V |
| Ultra-low current | 1.75 μA in one-shot mode |
| Temperature accuracy (max.) | ± 0.5 °C (-10 °C to +60 °C) |
Key Features
- Integrated temperature sensor with digital output for precise measurement.
- Surface mount 6-pin UDFN package measuring 2 x 2 x 0.55 mm.
- Supports I2C and SMBus 3.0 protocols with ALERT functionality.
- Operates within a wide temperature range from -40 °C to 125 °C.
- Ultra-low power consumption of 1.75 μA in one-shot mode for efficient usage.
- Factory calibrated sensor ensuring no additional calibration required.
- Programmable temperature thresholds with interrupt support for advanced control.
- Compact and exposed pad-down package enhances thermal coupling to the environment.
Product Description
STMicroelectronics MCP9701 digital output temperature sensor MCP9701 combines a band gap sensor, A/D converter, and signal processing within a compact 6-lead UDFN 2 x 2 x 0.50 mm package. It utilizes an I2C/SMBus 3.0 interface providing accurate temperature sensing with ±0.5 °C precision from -10 °C to +60 °C and operates from -40 °C to +125 °C.
This sensor is factory calibrated and designed for surface mount applications, featuring an exposed pad down design for superior thermal coupling with the environment, enabling precise temperature readings in industrial and consumer electronics.
Its one-shot mode achieves ultra-low current operation at 1.75 μA, making it ideal for battery-powered instrumentation and IoT devices. Programmable alarm thresholds with an interrupt pin facilitate integration into complex control systems with reliable alerts.
Compatible with supply voltages between 1.5 V and 3.6 V, this sensor supports up to 1 MHz serial clock speeds for efficient data communication using the I2C protocol. The 16-bit output provides high resolution temperature data ideal for laboratory, industrial automation, HVAC monitoring, and consumer electronics.
The STMicroelectronics MCP9701 sensor is suited for applications demanding reliable temperature measurement in compact form factors with low power consumption and high accuracy. It ensures seamless incorporation in electronic assemblies requiring precise thermal management.
Integrated Temperature Sensor with digital output for precise measurement. Surface mount 6-pin UDFN package measuring 2 x 2 x 0.55 mm. Supports I2C and SMBus 3.0 protocols with ALERT functionality. Operates within a wide temperature range from -40 °C to 125 °C.
Ultra-low power consumption of 1.75 μA in one-shot mode for efficient usage. Factory calibrated sensor ensuring no additional calibration required. Programmable temperature thresholds with interrupt support for advanced control.
Compact and exposed pad-down package enhances thermal coupling to the environment. Operates on supply voltages from 1.5 V to 3.6 V supporting various power systems. Provides 16-bit temperature data output with high resolution.
Explore more sensors and electronic components at EnvMart to find the perfect fit for your industrial and commercial electronic systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP9701 temperature sensor has an accuracy of ±0.5 °C within the temperature range of -10 °C to +60 °C.
This model operates within a wide temperature range from -40 °C to 125 °C.
It supports I2C and SMBus 3.0 protocols for communication.
The sensor operates on supply voltages ranging from 1.5 V to 3.6 V.
The MCP9701 comes in a surface mount 6-pin UDFN package measuring 2 mm x 2 mm x 0.55 mm.
In one-shot mode, the MCP9701 consumes ultra-low power at 1.75 μA.
No, the sensor is factory calibrated and does not require additional calibration.
It provides a digital output for temperature measurements.
The maximum operating temperature for this sensor is 125 °C.
The MCP9701 features programmable temperature thresholds with interrupt support for advanced control.
The height of the MCP9701 sensor is 550 μm.
The MCP9701 provides 16-bit temperature data output, offering high resolution for accurate measurements.
