Chinfa DC/DC Converter DRD30, 5V Output, 4.5A Current, 24V to 36V Input, 22.5W Power, 71°C Max Operating Temperature DRD30

Chinfa DRD30 DC/DC Converter is a compact, efficient power supply module designed for industrial and commercial electronic circuits. It provides a stable 5V output voltage with a maximum output current of 4.5A, and operates reliably within an input voltage range of 24V to 36V DC. Rated at 22.5W, this converter features a maximum operating temperature of 71°C and minimum operating temperature of -40°C, enabling use in diverse environmental conditions.

This converter belongs to the DRD30 series from Chinfa, known for their DIN rail mountable design with short circuit protection and internal input filtering. The DRD30 series includes multiple outputs and LED indicators for DC power presence and operation status. The internal surge voltage protection complies with IEC 61000-4-5, ensuring robustness against electrical disturbances.

Key technical advantages include an 81% efficiency rating which minimizes power loss, and compact dimensions of 91mm length, 56.5mm depth, and 35mm width that facilitate integration in tight spaces. The unit's isolation voltage rating of 1.5kV enhances safety and noise immunity in sensitive environments.

Certified to meet standards such as TUV, cUL, CE, cTUVus, and UL, this DC/DC converter is suitable for applications including building automation, factory automation, and industrial controls. It withstands vibration per IEC 60068-2-6 and mechanical shocks per IEC 60068-2-27, ensuring durability in demanding industrial settings.

Supports wide 24-36V input voltage for flexible power sourcing. Outputs 5V at 4.5A with 22.5W power capacity for stable performance. Short circuit protection and input filtering enhance operational safety. Compact DIN rail mount form factor simplifies installation.

Conforms to multiple international approvals guaranteeing quality standards. Robust against environmental vibrations and shocks common in industrial environments. Remote on/off functionality allows easy integration with control systems.

Ideal for industrial, commercial electronics, and automation control use cases. Explore more DC/DC Converters and power supply solutions on EnvMart for industrial electronics applications.
