Chinfa DIN Rail Power Supply 264V AC Input 12V DC 8.4A Output 100W DRA100

Chinfa DRA100 DIN Rail Power Supply offers robust and reliable power conversion for industrial control systems with universal AC input voltage range from 90V to 264V AC and DC input up to 375V. Featuring a single regulated 12V DC output rated at 100 W with a maximum current of 8.4 A, it supports a broad temperature range from -35°C to 71°C, suitable for demanding industrial environments.

This switch mode power supply features a compact DIN rail mount form factor with IP20 ingress protection, allowing for easy integration into electrical panels and control cabinets. The unit provides efficient energy conversion with 77.9% efficiency which reduces power loss and thermal impact.

Designed with multiple safety and EMC approvals including UL 62368-1, EN 55032, EN 61558, and UL 508, it meets stringent industry standards ensuring safety and reliability. The power supply includes internal input filtering and short circuit protection for secure operation in industrial automation settings.

The product offers versatile spring or screw terminal options for reliable wiring connections. Its dimensions of 90mm (H) x 54mm (W) x 114mm (D) make it suitable for compact installation spaces. The DRA100 series is backed by a 3-year warranty, enhancing its suitability for factory automation, process control, instrumentation, and building management systems.

Applicable in industrial, manufacturing, HVAC, and automation industries, this Chinfa DIN rail power supply is a dependable power solution for various control and instrumentation applications demanding consistent 12V DC output.

Universal mains input voltage range 90 - 264V AC for wide compatibility. Single 12V DC output delivering up to 8.4 A current. Compact design with IP20 rating suitable for DIN rail mount. Operating temperature range from -35°C up to +71°C for harsh conditions.

High energy efficiency at 77.9% minimizing power losses. Compliance with UL, EN, and TUV safety standards for industrial use. Front Vout adjustment for fine voltage regulation. Includes short circuit protection and internal input filter.

Dimensions: Height 90 mm, Width 54 mm, Depth 114 mm. Manufactured in Taiwan, Province Of China with 3-year warranty. Explore our wide range of DIN Rail Power Supplies at EnvMart for reliable industrial power solutions.
