Chinfa Single Output DIN Rail Power Supply 264V AC Input 12V DC 5A Output 60W DRAN60
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Chinfa |
| Power | 60W |
| Efficiency | 89% |
| Height | 90mm |
| Model | DRAN60 |
| Depth | 114mm |
| IP Rating | IP20 |
| Width | 40.5mm |
| Series | DRAN60 |
| Output Current | 5A |
| Maximum Operating Temperature | 71°C |
| Sub Type | Single Output |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 264V ac |
| Electrical Phase | 1 |
| Maximum Output Voltage | 12V dc |
| Minimum Input Voltage | 85V ac |
Key Features
- Operates with universal AC input voltage from 85V to 264V.
- Maintains efficiency of up to 89% ensuring energy saving operation.
- Compact design with dimensions 90mm height, 114mm depth, and 40.5mm width.
- Supports operating temperature range from -40°C to 71°C for industrial environments.
- Provides IP20 protection rating suitable for indoor DIN rail installations.
- Includes regulated output voltage with remote DC-OK signal indication.
- Meets international standards EN 55032, EN 61558, EN 62368-1, UL 508, and UL 62368-1.
- Designed for industrial control automation with short circuit protection and internal input filter.
Product Description
Chinfa DRAN60 is a single output DIN rail power supply designed for industrial control automation applications requiring stable 12V DC output at 5A and 60W power.
This power supply features a universal AC mains input range from 85V up to 264V, allowing flexible installation in various regions and systems. Its switch mode design incorporates short circuit protection and an internal input filter to ensure robust and reliable power delivery under fluctuating electrical conditions.
The compact form factor, measuring 90mm in height, 114mm in depth, and 40.5mm width, allows easy mounting on standard DIN rails inside electrical enclosures. It supports IP20 ingress protection rating, protecting internal components from solid objects and suitable for indoor industrial environments.
Operating over a wide temperature range from -40°C to 71°C, it can withstand harsh industrial conditions. The DRAN60 series power supply also provides a remote DC-OK signal for status monitoring.
Universal AC input voltage: 85-264V AC. Single regulated DC output: 12V, 5A, 60W power. High efficiency of 89% reduces energy consumption. Compact DIN rail mount design with IP20 protection. Wide temperature range operation from -40°C to 71°C.
Short circuit protection and internal input filtering. Compliance with EN 55032, EN 61558, UL 508, and IEC safety standards.
Chinfa DRAN60 power supplies are widely used in industrial automation, manufacturing control panels, HVAC control systems, and electrical equipment requiring reliable and safe DC power. Their robust design and international certifications ensure suitability for demanding environments.
Explore EnvMart's comprehensive selection of DIN Rail Power Supplies for industrial and commercial applications to find compatible products meeting your exact specifications.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a single regulated DC output of 12V at 5A, with a total power output of 60W.
The efficiency of this power supply is up to 89%, ensuring energy-saving operation.
The compact design measures 90mm in height, 114mm in depth, and 40.5mm in width.
This power supply includes short circuit protection and an internal input filter for reliable power delivery.
The DRAN60 has an IP20 protection rating, making it suitable for indoor DIN rail installations.
It meets several international standards including EN 55032, EN 61558, UL 508, and UL 62368-1.
This model features a single output.
It is designed for industrial control automation, manufacturing control panels, and HVAC control systems.
The DRAN60 operates on a single electrical phase.
The country of origin for this power supply is Taiwan.
