| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 0.8mm |
| Length | 2.7mm |
| Model | BZX84J-B10,115 |
| Mount Type | Surface |
| Series | BZX84J |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 550mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 200nA |
| Nominal Zener Voltage Vz | 10V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 10Ω |
| Typical Voltage Temperature Coefficient | 4.5mV/K |
| Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand | DiodesZetex |
| - Non-repetitive Peak reverse power dissipation | 40mW |
| - Total power dissipation | 550mW |
| - Wide working voltage range | nominal 2.4V to 75V (E24 range) |
| - Two tolerance series | 2% and 5% |
Nexperia BZX84J-B10,115 Zener Diode is a single element semiconductor device rated for 10 V nominal Zener voltage with a narrow 2% tolerance. This device is housed in a small 2-pin SOD-323 surface mount package suitable for compact circuit designs requiring voltage regulation or protection.
Power dissipation is rated at a maximum of 550 mW, supporting steady performance in voltage stabilization applications. The diode supports a test current of 5 mA and demonstrates a low reverse leakage current of 200 nA which ensures high device efficiency and minimal power loss.
The diode withstands a wide operating temperature range from -55°C to 150°C, making it suitable for use in automotive and industrial environments. Additionally, it meets the stringent automotive AEC-Q101 qualification, confirming its reliability in automotive systems.
The package dimensions of 2.7 mm length and 0.8 mm height allow for its integration into miniature surface-mount load boards. With a stable zener impedance max of 10 ohms, it offers precise voltage clamping and regulation.
Single diode configuration ideal for voltage regulation applications. Nominal zener voltage of 10 volts with ±2% tolerance. Compact SOD-323 surface mount package with 2 pins. Maximum power dissipation rating of 550 mW supporting stable operation.
Operating temperature range from -55°C to 150°C for wide environmental conditions. Test current set at 5 mA for device characterization. Low maximum reverse leakage current of 200 nA ensuring efficiency. Complies with automotive standard AEC-Q101 for reliable automotive use.
Small size with length 2.7 mm and height 0.8 mm for miniature designs. Stable impedance of maximum 10 ohms for precise voltage clamping.
This Zener Diode is commonly applied in industrial electronics, automotive voltage regulation, power supply protection, and precision reference voltage circuits. It offers compact size and robust operational parameters ideal for modern surface mount electronic assemblies.
